User's Manual

Page 14 of 22
Operation
WELL Panel User Manual Rev. 2
8 Color macro
000  010 No function
011  030 R: 100% G: 0–100% B: 0%
031  050 R: 100–0% G: 100% B: 0%
051  070 R: 0% G: 100% B: 0–100%
071  090 R: 0% G: 100–0% B: 100%
091  110 R: 0–100% G: 0% B: 100%
111  130 R: 100% G: 0% B: 100–0%
131  150 R: 100% G: 0–100% B: 0–100%
151  170 R: 100% G: 100–0% B: 100%
171  200 R: 100% G: 100% B: 100%
201  205 Dark amber
206  210 Amber
211  215 Light amber
216  220 Dark pink
221  225 Pink
226  230 Light pink
231  235 No color pink
236  240 No color blue
241  245 Light blue
246  250 Cornflower blue
251  255 Light pale blue
9 Color temperature
000  005 No function
006  025 2800K
026  050 3200K
051  075 3500K
076  100 4000K
101  125 4500K
126  150 5000K
151  175 5600K
176  200 6000K
201  225 6500K
226  255 No function
10 Auto programs
000 
010 No function
011  037 Auto program 1
038  064 Auto program 2
065  091 Auto program 3
092  118 Auto program 4
119  145 Auto program 5 (Auto program 1–4)
146  172 Auto program 6
173  199 Auto program 7
200  226 Auto program 8
227  255 Auto program 9 (Auto program 6–8)
11 Auto program speed 000  255 Auto speed, slow to fast
12 Dimmer speed mode
000  051 Preset dimmer speed from display menu
052  101 Dimmer speed mode off
102  152 Dimmer speed mode 1 (fastest)
153  203 Dimmer speed mode 2
204  255 Dimmer speed mode 3 (slowest)
Channel Function Value Percent/Setting
