User's Manual

Page 13 of 22
WELL Panel User Manual Rev. 2
Operation
13Ch
17 Color temperature
000  005 No function
006  025 2800K
026  050 3200K
051  075 3500K
076  100 4000K
101  125 4500K
126  150 5000K
151  175 5600K
176  200 6000K
201  225 6500K
226  255 No function
18 Auto programs
000  010 No function
011  037 Auto program 1
038  064 Auto program 2
065  091 Auto program 3
092  118 Auto program 4
119  145 Auto program 5 (Auto program 1–4)
146  172 Auto program 6
173  199 Auto program 7
200  226 Auto program 8
227  255 Auto program 9 (Auto program 6–8)
19 Auto program speed 000  255 Auto speed, slow to fast
20 Dimmer speed mode
000  051 Preset dimmer speed from display menu
052  101 Dimmer speed mode off
102  152 Dimmer speed mode 1 (fastest)
153  203 Dimmer speed mode 2
204  255 Dimmer speed mode 3 (slowest)
21 Red shift
000  010 No function
011  127 On
128  255 Off
Channel Function Value Percent/Setting
1Dimmer 000  255 0–100%
2 Fine dimmer 000  255 0–100%
3Red 000  255 0–100%
4Green 000  255 0–100%
5Blue 000  255 0–100%
6White 000  255 0–100%
7 Strobe
000  010 No function
011  255 Strobe, slow to fast
Channel Function Value Percent/Setting
