Manual
Table Of Contents
- INTRODUCTION
- HOW TO USE THIS MANUAL
- INSTALLATION CHECKLIST
- INSTALLATION GUIDE
- Preparation
- Hardware Installation
- Serial Setup – Access The PDU Using The Serial Connection
- Step 1: Download the PDU Serial Access Program
- Step 2: Connect the Computer to the PDU
- Step 3: The Main Menu – Navigating The Serial Access Program
- Step 4a: The Configure Menu – Configuring The PDU For SEMA Or SNMP
- Step 4b: The Web Menu – Configuring The PDU For Web Browser Access
- Step 5: The Monitor Menu – Monitoring The PDU With A Serial Connection
- Ethernet Setup – Access The PDU Using The Ethernet Connection
- Step 1: Configuring the Browser
- Step 2: Connect the PDU to the Network
- Step 3: Logging onto the PDU
- Step 4: The Main Menu – Navigating The Web Access Program
- Step 5: The User Menu – Assign User Passwords
- Step 6: The Configure Menu – Configure The PDU For Your Network
- Step 7: The Monitor Menu – Monitoring The PDU Using A Web Browser
- TROUBLESHOOTING GUIDE
- APPENDIX
CPI PDU User Manual Rev. 10.0. June 28, 2010
2
INTRODUCTION
This document is the User’s Manual for rack-mount Monitored and Controlled PDUs by
Chatsworth Products, Inc. (CPI).
CPI rack-mount Monitored and Controlled PDUs provide current monitoring over the
network and are accessible though a Java-compatible Web Browser or CPI’s Scalable
Enterprise Management Application (SEMA) software. The PDUs can be accessed
through other applications/appliances via SNMP and can be accessed with provided
software using a direct serial connection to a computer. All models include a current
meter with a digital display. Controlled PDUs include switched outlets/receptacles
allowing power to be turned on or off and remotely cycled to each controlled port
(outlet/receptacle). Controlled PDUs also measure current use at each controlled port
(outlet/receptacle).
CPI rack-mount Monitored and Controlled PDUs are part of CPI’s Enterprise
Infrastructure Solutions and can be used with CPI’s SEMA software, CenterLine,
CenterBridge and PowerScope In-Line Meters to provide enterprise-wide, web-based
KVM switch access to devices (computer and network switch equipment), asset
management and power monitoring.
