APPENDIX
Factory Default Setting
Configuration variables for the PDU:
Log Interval = 0
Alarm Interval = 0
Log Difference = 0
PDU Connection Port = 2001
SEMA Connection Port = 2002
PDU Broadcast Port = 2003
SEMA Broadcast Port = 2004
SEMA IP Address = 0.0.0.0
PDU IP Address = 192.168.123.123
PDU MAC Address = 0:0:0:0:0:0
Subnet Mask = 255.255.255.0
Gateway = 192.168.123.1
AutoIP and Hosts checkboxes are unchecked
WEB and SWU checkboxes are checked
SNMP Host1 IP Address = 0.0.0.0
SNMP Host2 IP Address = 0.0.0.0
SNMP Host3 IP Address = 0.0.0.0
PDU Name = pduname
PDU Password = <blank>
SEMA Name = <blank>
SEMA Password = <blank>
Min Temperature = 0
Max Temperature = 0
Min Humidity = 0
Max Humidity = 0
Socket Name = recepNamexx (xx suffix is the socket number)
ON Delay = 3 (for all receptacles)
Reset Delay = 5 (for all receptacles)
Power ON = ON (for all receptacles)
Maximum Current = 14.90 (for all branches)
Maximum Socket Lock Current = 14.90 (for all branches)
