Specifications

ManualsBrandsCharlton Home ManualsCeiling LightsPooler 1 - Light 13.25" Simple Bowl Flush Mount

Project:

Fixture Type:

Location:

Contact:

Images:

Description:

One-light LED close to ceiling with etched glass bowl and replaceable LED module in a Brushed

Nickel ﬁnish.

Speciﬁcations:

Performance:

Number of Modules 

Input Power w

Input Voltage  V

Input Frequency  Hz

Lumens/LPW (Source) /. (LM-)

Lumens/LPW (Delivered) ./. (LM-)

CCT  K

CRI  CRI

Life (hours) , (L/TM-)

FCC Meets FCC Title , Part  Class B

Min. Start Temp - °C

Max. Operating Temp  °C

Warranty  year warranty

Labels cCSAus Damp location listed

ENERGY STAR

qualiﬁed

Dimensions:

Diameter: 13-1/4"

Height: 4-3/4"

Glass

Width: 11-5/16"

Length: 11-5/16"

Height: 3-15/16"

One-Light Close-To-Ceiling

Ceiling ctc mounted • Damp location listed

• Brushed Nickel (plated)

• Steel Construction

• Etched glass bowl

• LED Module is replaceable

• , lumens . lumens/watt per module (source)

• K color temperature, + CRI.

• Dimmable to % brightness (See Dimming Notes)

• Ceiling pan covers a standard " octagonal recessed outlet box

• Mounting strap for outlet box included

• " of wire supplied

• ENERGY STAR

qualiﬁed

Summary of content (3 pages)

PAGE 1
Project: Fixture Type: Location: Contact: One-Light Close-To-Ceiling Ceiling ctc mounted • Damp location listed Description: One-light LED close to ceiling with etched glass bowl and replaceable LED module in a Brushed Nickel finish. Images: Specifications: • • • • • • • • • • • Brushed Nickel (plated) Steel Construction Etched glass bowl LED Module is replaceable 1,211 lumens 71.2 lumens/watt per module (source) 3000K color temperature, 90+ CRI.
PAGE 2
One-Light Close-To-Ceiling Ceiling ctc mounted • Damp location listed Photometrics: ELECTRICAL DATA Input Voltage 120 V Input Frequency 60 Hz Input Current 0.142 A Input Power 17 Power Factor Greater than 0.90 THD <20% FCC Meets FCC Title 47, Part 15 Class B Operating Temperature -30 °C to 30 °C Dimming Yes* *See Dimming Notes for more information PAGE: 4 OF 9 LED Light Engine: 3000 K 90 CRI System Wattage: 17 Fixture delivered lumens: 974.42 Fixture Efficacy: 58.
PAGE 3
One-Light Close-To-Ceiling Ceiling ctc mounted • Damp location listed Dimming Notes: This light is designed to be compatible with many ELV/Reverse Phase controls. The following is a partial list of known compatible dimmer controls. Dimming Controls Lutron Nova T NTELV-300 Lutron Vierti VTELV-600 Lutron Maestro MAELV-600 Lutron spacer/system SPSELV-600 Leviton Renoir II AWRMG-EAW Dimming capabilities will vary depending on the dimmer control, load, and circuit installation.
