Controls - 28 2450GR Operator’s Manual
Software
CMW
5. Phone cable button To mark a radar image as a phone
cable, press.
6. Sewer pipe button To mark a radar image as a sewer
pipe, press.
7. Water pipe button To mark a radar image as a water
pipe, press.
8. Unknown object button To mark a radar image as an unknown
object, press.
9. CANCEL button To exit the Mark Window without
selecting a marker, press.
10. FITTING button Press to open a window to enter
formulated depth of a pipe or cable.
Use the UP and DOWN button to
adjust the white-line curve to the
shape of the hyperbola.
11. GROUND TRUTH
SKETCH button
Press to open a window to enter exact
depth of a pipe or cable.
Use when information is
available from another
source, such as technical
maps or actual measurement.
Item Description Notes
