Operator's Manual

Controls - 26 2450GR Operator’s Manual
Software
CMW
3. MARK / UNMARK
buttons
To mark an image on the radar map,
position cursor and press MARK. The
Mark Window will open.
To remove a previously placed mark,
position cursor and press UNMARK.
4. Distance display Displays distance traveled from
starting point.
Displays object depth of detected
object.
5. END EDITING button To close the Acquisition Editing
window, press.
6. PRINT button To print radar map with information,
press.
7. - / File Name / + To select and load previous scans in a
survey, press -.
To go to a particular scan, press the
arrow and select.
To select and load subsequent scans
in a survey, press +.
8. Directional arrow
buttons
To move the review line about 20”
(50 cm) to the left, press <<.
To move the review line about 1”
(2.5 cm) to the left, press <.
To move the review line about 1”
(2.5 cm) to the right, press >
To move the review line about 20”
(50 cm) to the right, press >>.
On touch sensitive tablet
PCs, you may reposition the
review line by tapping the
screen.
Item Description Notes
