Operator's Manual

2450GR Operator’s Manual Controls - 19
Software
CMW
2. Advanced settings
toggle bar
To open the advanced settings
window, press the gray bar twice. In
this window you can customize the
way information is displayed.
Wheel Setting
• Wheel driven (default): radar acquisition is set using the
position sensor.
• Auto stacking: Radar acquisition is set using a number you
enter.
Ground Type
• Rough terrain: Select this setting when ground conditions
cause excessive vibration. In this mode, radar data is
temporarily saved on an external device during the acquisition
phase.
• Device: Select the computer port the external device is
connected to.
Measure Unit: Select standard or metric measurement units.
Swap Axis: Select m or nsec to modify the vertical scale of the radar
map.
Background Removal: Select this option to viewed radar maps with or
without the Clear_x application.
Gain Application: Select this option to view the real time radar map
with or without gain applied.
Language: Select to view the software interface in Italian or English.
3. System status
indicators
Indicators for radar, battery,
acquisition speed, and acquired
sweeps light when active.
4. CONFIGURATION
button
5. Frequency setting
buttons
Select shallow (high frequency,
700MHz)
Select deep (low frequency, 250 MHz)
The 2450GR transmits,
receives, and records both
frequencies at all times. Use
this button to view low, high,
or both frequencies while
scanning.
6. END PROGRAM To exit Acquisition Software, press.
Item Description Notes
