Operator's Manual

Controls - 18 2450GR Operator’s Manual
Software
CMW
Software
Acquisition Setup Window
1. Scan display area
2. Advanced settings toggle bar
3. System status indicators
4. CONFIGURATION button
5. Frequency setting buttons
6. END PROGRAM button
7. SKIP CALIBRATION button
8. END CALIBRATION button
9. START CALIBRATION button
Item Description Notes
1. Scan display area Displays radar information from the
antenna.
Measurement scale on the
left indicates depth below the
surface.
