2450GR Operator’s Manual Overview - 2 Serial Number Location Serial Number Location Record serial numbers and date of purchase in spaces provided. Serial numbers are located as shown.
2450GR Operator’s Manual Overview - 3 Overview Overview 1. Tablet PC 5. Wheel position sensor 2. Cart 6. Control unit 3. Antenna 7. Battery charger 4. Battery Item Description Notes 1. Tablet PC Operates the Scan Acquisition Software and receives data from the control unit. For specific information about the Tablet PC, see the documentation provided by the PC manufacturer. 2. Cart Carries GPR components over a variety of terrain. Collapses for easy transport.
2450GR Operator’s Manual Overview - 4 Overview Item Description Notes 3. Antenna Digital radar transmitter/receiver that uses two frequencies to detect buried pipes. The 2450GR scans and records both frequencies simultaneously at all times. High frequency (700MHz) has shallow penetration. Best in conditions with good radar conductivity, such as ice, sand, concrete, or rock. Low frequency (250 MHz) has broad, deep penetration.
2450GR Operator’s Manual Overview - 5 Intended Use Intended Use The 2450GR is a ground penetrating radar system that detects metallic and non-metallic pipes and cables buried underground. Following standard radar principles, the 2450GR uses a high performance electromagnetic sensor equipped with electromagnetic transmitters and recievers to identify underground utilities and transmit the location data to a portable computer where specialized software maps the location site.
2450GR Operator’s Manual Overview - 6 Compliance Compliance This equipment conforms to the following requirements set by EC regulations, including subsequent modifications, and to the legislation set by the member states that implement these regulations: • 1999/5/EC Radio and Telecommunications Terminal Equipment Directive • 2006/95/EC Low Voltage Equipment Directive WARNING: this equipment is designed for use in industrial environments (Class A apparatus).
2450GR Operator’s Manual Foreword - 7 Foreword This manual is an important part of your equipment. It provides safety information and operation instructions to help you use and maintain your Subsite Electronics equipment. Read this manual before using your equipment. Keep it with the equipment at all times for future reference. If you sell your equipment, be sure to give this manual to the new owner. If you need a replacement copy, contact your Subsite Electronics dealer.
2450GR Operator’s Manual Foreword - 8 2450GR Operator’s Manual Issue number 1.0/OM-11/19/10 Part number 053-xxxx DRAFT 2 Copyright 2010 by The Charles Machine Works, Inc. , Ditch Witch, CMW, AutoCrowd, Jet Trac, Roto Witch, Subsite, Fluid Miser, Power Pipe, Super Witch, Pierce Airrow, The Underground, The Underground Authority Worldwide, and Zahn are registered trademarks of The Charles Machine Works, Inc. OnGrade is a pending trademark of The Charles Machine Works, Inc.
2450GR Operator’s Manual Contents - 9 Contents Overview 1 Foreword 7 Safety 11 Controls 15 Prepare 29 Operate 35 machine serial number, information about the type of work this machine is designed to perform, basic machine components, and how to use this manual part number, revision level, and publication date of this manual, and factory contact information machine safety alerts and emergency procedures machine controls, gauges, and indicators and how to use them an overview for completing a
Contents - 10 CMW 2450GR Operator’s Manual
2450GR Operator’s Manual Safety - 11 Safety Chapter Contents Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Safety Alert Classifications . . . . . . . . . . . . . . . . . . 13 Safety Alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety - 12 2450GR Operator’s Manual Guidelines Guidelines Follow these guidelines before operating any jobsite equipment: • Complete proper training and read operator’s manual before using equipment. • Contact One-Call (811 in USA) or the One-Call referral number (888-258-0808 in USA and Canada) to have underground utilities located before working. Also contact any utilities that do not participate in the One-Call service.
2450GR Operator’s Manual Safety - 13 Safety Alert Classifications Safety Alert Classifications These classifications and the icons defined on the following pages work together to alert you to situations which could be harmful to you, jobsite bystanders or your equipment. When you see these words and icons in the book or on the machine, carefully read and follow all instructions. YOUR SAFETY IS AT STAKE. Watch for the three safety alert levels: DANGER, WARNING and CAUTION. Learn what each level means.
2450GR Operator’s Manual Safety - 14 Safety Alerts Safety Alerts Electric shock. Contacting electric lines will cause death or serious injury. Know location of lines and stay away. Jobsite hazards could cause death or serious injury. Use correct equipment and work methods. Use and maintain proper safety equipment. Explosion possible. Serious injury or equipment damage could occur. Follow directions carefully. Incorrect procedures could result in death, injury, or property damage.
2450GR Operator’s Manual Controls - 15 Controls Chapter Contents Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 • Radar Setup Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 • Acquisition Selection Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2450GR Operator’s Manual Controls - 16 Antenna Antenna 1. Antenna lift/lower strap 3. Cart mounting pins 2. Control unit port 4. Antenna centerpoint marker Item Description 1. Antenna lift/lower strap Connects to a knob on the top of the cart to lift the antenna off the ground. During operation, disconnect strap from knob so antenna contacts ground. 1. Control unit port Connects to the control unit antenna port (ANT 1). 2.
2450GR Operator’s Manual Controls - 17 Control Unit Control Unit 1. Power supply port (BATTERY) 4. Wheel position sensor port (WHEEL) 2. Network port (LAN) 5. Power button. 3. Antenna port (ANT 1) Item Description Notes 1. Power supply port (BATTERY) Connects the control unit to the battery. Blue indicator lights when system is powered by the battery. 2. Network port (LAN) Connects the control unit to the notebook PC. 3. Antenna port (ANT 1) Connects the control unit to the antenna. 4.
2450GR Operator’s Manual Controls - 18 Software Software Acquisition Setup Window 1. Scan display area 6. END PROGRAM button 2. Advanced settings toggle bar 7. SKIP CALIBRATION button 3. System status indicators 8. END CALIBRATION button 4. CONFIGURATION button 9. START CALIBRATION button 5. Frequency setting buttons Item Description Notes 1. Scan display area Displays radar information from the antenna. Measurement scale on the left indicates depth below the surface.
2450GR Operator’s Manual Controls - 19 Software Item Description 2. Advanced settings toggle bar To open the advanced settings window, press the gray bar twice. In this window you can customize the way information is displayed. Notes Wheel Setting • Wheel driven (default): radar acquisition is set using the position sensor. • Auto stacking: Radar acquisition is set using a number you enter. Ground Type • Rough terrain: Select this setting when ground conditions cause excessive vibration.
2450GR Operator’s Manual Controls - 20 Software Item Description Notes 7. SKIP CALIBRATION To bypass calibration, press. If you skip calibration, you will only be able to view preexisting radar maps. 8. END CALIBRATION To stop calibrating parameters, press. 9. START CALIBRATION To start calibrating parameters, press. 10. Palette selection button To select color and resolution for viewing radar maps, press, then select the desired palette. 11. Zoom button To make the radar map larger, press.
2450GR Operator’s Manual Controls - 21 Software Acquisition Selection Window 1. File display window 5. NEW ACQUISITION button 2. REVIEW ACQUISITION button 6. RESUME LAST ACQUISITION button 3. RENAME ACQUISITION button 7. BACK TO SETUP button 4. DELETE ACQUISITION button 8. EXIT PROGRAM button Item Description 1. File display window Displays a list of acquisitions saved at C:\2450GR\mission\directory. 2.
2450GR Operator’s Manual Controls - 22 Software Item Description Notes 5. NEW ACQUISITION button To save a new acquisition, enter a name in the text box and press. Files are saved at c:\2450GR\mission\directory The New Acquisition Window will open. 6. RESUME LAST ACQUISITION button To continue scanning and save the data to the last acquisition, select file in display window, then press. 7. BACK TO SETUP button Press to open the Acquisition Setup Window and recalibrate the 2450GR. 8.
50GR Operator’s Manual Controls - 23 Software New Acquisition Window 1. Scan display window 5. END ACQUISITION button 2. Contrast setting 6. SAVE SCAN button 3. Edit Parameters 7. STOP SCAN button 4. Notes 8. START SCAN button Item Description 1. Scan Display Window Displays real time ground penetrating radar image. Also displays survey name, scan number, and distance traveled. 2. Contrast setting window To increase or decrease radar map contrast, press, then select the desired setting.
2450GR Operator’s Manual Controls - 24 Software Item Description 5. END ACQUISITION button To end the current acquisition, press. 6. SAVE SCAN button To save scan, press. 7. STOP SCAN button To stop scanning, press. 8. START SCAN button To begin displaying scanned radar image, press. The Acquisition Editing Window will open.
2450GR Operator’s Manual Controls - 25 Software Acquisition Editing Window 1. Radar map display 5. END EDITING button 2. UP / DOWN buttons 6. PRINT button 3. MARK / UNMARK buttons 7. - / File Name / + buttons 4. Distance display 8. Directional arrow buttons Item Description 1. Radar map display Displays real time ground penetrating radar image. Also displays survey name, scan number, depth, and distance traveled. 2. UP / DOWN buttons To move the cursor up, press UP.
2450GR Operator’s Manual Controls - 26 Software Item Description 3. MARK / UNMARK buttons To mark an image on the radar map, position cursor and press MARK. The Mark Window will open. Notes To remove a previously placed mark, position cursor and press UNMARK. 4. Distance display Displays distance traveled from starting point. Displays object depth of detected object. 5. END EDITING button To close the Acquisition Editing window, press. 6. PRINT button To print radar map with information, press.
2450GR Operator’s Manual Controls - 27 Software Mark Window 1. Gas pipe button 7. Water pipe button 2. Traffic control cable button 8. Unknown object marker 3. Electrical cable button 9. CANCEL button 4. Street light cable button 10. FITTING button 5. Phone cable button 11. GROUND TRUTH SKETCH button 6. Sewer pipe button NOTICE: The 2450GR can not identify types of pipe or cable. Find this information from other sources, such as opening manholes or consulting technical maps.
2450GR Operator’s Manual Controls - 28 Software Item Description 5. Phone cable button To mark a radar image as a phone cable, press. 6. Sewer pipe button To mark a radar image as a sewer pipe, press. 7. Water pipe button To mark a radar image as a water pipe, press. 8. Unknown object button To mark a radar image as an unknown object, press. 9. CANCEL button To exit the Mark Window without selecting a marker, press. 10.
2450GR Operator’s Manual Prepare - 29 Prepare Chapter Contents Survey the Site . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 • Inspect Visually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 • Acquire Utility Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Check Battery Status . . . . . . . . . . . . . . . . . . . . . . .
Prepare - 30 2450GR Operator’s Manual Survey the Site Survey the Site Consider the following when preparing to work at a survey site: • Gain permission to access pedestrian zones, interrupt traffic flow, etc. • Determine site accessibility. • Determine space available for cart. • Observe traffic levels. • Observe presence of parked cars. • Observe presence of architectural obstacles.
2450GR Operator’s Manual Prepare - 31 Setup Setup 1. To open cart, remove pin (1), rotate handle (2) to upright position, and insert pin into slot. 2. To adjust height, pull knob (1) and raise or lower the handle (2) to desired height. Release knob to engage pin.
Prepare - 32 2450GR Operator’s Manual Setup 3. To attach computer to cart, align velcro strips on bottom of computer with velcro strips on cart. 4. Connect network cable from control unit to computer. 5. To lower antenna into scan position, pull rubber keeper (1) until it is free from pin (2).
2450GR Operator’s Manual Prepare - 33 Check Battery Status Check Battery Status Control Unit Check battery status before each use, after each battery change, and as desired during operation. In normal conditions, battery lasts about 12 hours. To check 1. Connect control unit to battery. 2. Check battery status: Control Unit If battery has greater than 10V, indicator on control unit will light. Software Check battery status indicator. • If indicator is green, battery is fully charged.
Prepare - 34 2450GR Operator’s Manual Check Battery Status CMW
2450GR Operator’s Manual Operation - 35 Operation Chapter Contents Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 • Launch Acquisition Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 • Calibrate System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 • Acquire Scan Data . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation - 36 2450GR Operator’s Manual Setup Setup Position 2450GR at jobsite and release rubber keeper to lower antenna to ground. Launch Acquisition Software The 2450GR software allows scan data to be acquired, saved, and viewed directly in the field. 1. Set the control unit power switch to ON. 2. Turn on the tablet PC. (See manufacturer’s instructions for more information.) 3. Click the 2450GR icon to launch the software. 4. Monitor progress of software self-tests.
2450GR Operator’s Manual Operation - 37 Scan Scan Acquire Scan Data Ensure that the New Acquisition Window is open. 1. Press START SCAN and push or pull the cart to acquire survey data. Note: The 2450GR can be either pulled or pushed to acquire survey data; however, the entire acquisition must be conducted in the same direction. Follow a grid pattern to scan the survey area. 2. A radar map will appear on the computer display. Select Shallow, Deep, or Dual to set frequency viewing preference.
Operation - 38 2450GR Operator’s Manual Scan Mark Objects 1. When a hyperbola (1) is appears , move the cart in the opposite direction. A vertical white line (2) will display on the radar map. Move the cart until the white line is in the center of the hyperbola. 2. Mark the ground: Use spray paint to mark the location on the ground (shown). A red arrow on the side of the antenna corresponds to the white line on the radar map. 3.
2450GR Operator’s Manual Operation - 39 Scan Record Target Information Record target information during a survey, or at a later time. See “Acquisition Editing Window” on page 25. 1. Press the FITTING button (2), then Use the UP and DOWN buttons (3) to adjust the curve to match the hyperbolas. This sets the correct propagation speed to accurately calculate object depth. 2. Select an icon to label the type of pipe you suspect.
Operation - 40 2450GR Operator’s Manual Scan Troubleshoot Error Messages Message Description/Solution Network error. Retry or check hardware! Check that the network cable is connected properly to the PC and the control unit. Restart the program. New depth must be >0. Please insert new value to continue. New depth must be >0. Unable to set the depth. New depth missing. Please insert value to continue. Select a new value for the depth of the identified pipe. Warning.
2450GR Operator’s Manual Service - 41 Service Chapter Contents As Needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 • Clean 2450GR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 • Replace detector battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Load Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 • System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service - 42 2450GR Operator’s Manual As Needed As Needed Clean 2450GR Use a damp cloth to clean the 2450GR. IMPORTANT: • Before cleaning any external parts of the 2150GR, make sure all cables have been disconnected, including the power supply cable. • Make sure that cloth is not too wet to avoid any damage to the electrical components of the equipment. • Do not use solvents or abrasive detergents. • Do not apply liquid directly to the electrical contacts of the various connectors.
2450GR Operator’s Manual Service - 43 As Needed Load Software System Requirements Subsite Electronics recommends the Xplore tablet PC for optimum data processing with the 2450GR Ground Penetrating Radar unit.
Service - 44 2450GR Operator’s Manual As Needed CMW
2450GR Operator’s Manual Specifications - 45 2450GR Specifications 2450GR Dimensions U.S. Metric L, overall length, handle extended fully 40.0 in 1016 mm Length, handle collapsed, travel position 40.0 in 1016 mm H1, height from ground to handle extended fully 40.0 1016 mm H2, height handle folded 20.5 521 mm W, width 21 in 533 mm Weight, without PC 68.6 lb 31.
Specifications - 46 2450GR Operator’s Manual 2450GR Antenna Performance U.S. Metric Antenna technology: ultra-wide band, ground coupled, shielded dipole. 250 MHz: typical range 0.6-8.2 ft 0.2-2.5 m maximum range 0.6-19.7 ft 0.2-6.0 m typical range 0.32-4.9 ft 0.1-1.5 m maximum range 0.32-19.7 ft 0.1-8.2 m typical range 0.32-8.2 ft 0.1-2.5 m maximum range 0.32-19.7 ft 0.1-6.0 m System U.S. Metric Survey path width 19.
2450GR Operator’s Manual Specifications - 47 2450GR Software Display mode grayscale/color Zoom up to 4x Stored data format raw data (for further data analysis) Setting of GPR propagation velocity (to get accurate evaluation of depth of detected targets) ground truth or hyperbola fitting methods Reading of pipe position/depth software cursor System output printable annotated radar map Diagnostic radar and power supply status, excessive speed, data loss Languages English, French, German, Spa
Specifications - 48 2450GR Operator’s Manual 2450GR CMW
2450GR Operator’s Manual Support - 49 Procedure Support Procedure Notify your dealer immediately of any malfunction or failure of Ditch Witch Subsite Electronics equipment. Always give model, serial number, and approximate date of your equipment purchase. This information should be recorded and placed on file by the owner at the time of purchase. Return damaged unit to dealer for inspection and warranty consideration if in warranty time frame.
