Operators Manual

9
ENGLISH 12090
OPERATION
If the wire cable becomes kinked or twisted
during operation stop use immediately.
CAUTION
Do not exceed rated load capacity, even while
testing a load.
WARNING
Inspection
Before use of the utility winch, always inspect
the winch, power connections, wire cable, load
connections, and winch area for any possible
damage or hazards. Never connect a load to or
operate a winch, if it or any of it’s parts appear to
be worn or damaged.
Connecting a Load
During connection of a load and operation of
the winch, the user should keep hands and
fingers clear of pinch points, moving parts, the
wire cable and hook. Lose clothing and jewelry
should not be worn, and long hair should be tied
back while connecting a load and operation.
Gloves and safety goggles should be worn at all
times when connecting or winching a load. The
cable should never be allowed to slide through
the users hands. The user should only grab the
hook, using a hook strap (not included) when
loading/unloading an item. Never grab the wire
cable directly. Attach the load to the hook using
only rated equipment, such as slings, chains or
winching shackles. Connection to the hook must
be completely secure to prevent any accidental
disconnection. Make sure the connection device
is properly seated in the base of the hook and
that the safety clasp closes fully.
Always check the wire cable for any wear, fraying
or damage. Only wire cable in good condition
should be used. If the wire cable appears worn,
frayed or damaged, DO NOT connect any load to or
use, replace immediately.
Incorrect Incorrect Correct
Inspect the wire cable to make sure it is spooled
correctly. The wire cable should not be overlapping
on itself, have space between the rolls or slack in
it. If the wire cable is spooled incorrectly do not
connect a load to it or use it until the wire cable
has been re-spooled correctly.
Once a load has been properly connected,
drape a blanket or jacket over the wire cable
approximately 5 to 6 ft. (1.5 to 1.8 m) from
the hook. In the event of a broken cable it will
dampen the snap back. Make sure and do a test.
Winch the load 1 to 2 in. (2.5 to 5.1 cm) and
pause a moment to inspect all connections and
that the equipment can handle the load.
It is highly recommended that random
inspections also be done during operation.
NOTE
