FibeAir 1500 Installation & Operation Manual Chapter 5. Operation
Revision 2.0 The Work Area Window 5-3
5.3.1. Title Bar
The title bar of the Work Area window displays the following information:
Figure 5-3 Title Bar
Note that the "name of terminal" is user-defined via the General Information
window (Configuration ½ System Information). See section 4.4 for
details.
Closing the Working Area window by clicking on the "close window" button,
on the right side of the title bar is tantamount to logging out of the system.
5.3.2. Menu Bar
The menu bar of the Work Area window allows you to select options from
six menus.
Figure 5-4 Menu Bar
Below is a list of the various menus and the options they offer:
Figure 5-5 File Menu
Figure 5-6 Configurations Menu
FibeAir
Logo
Name of
terminal
Name of
window
Minimize
window
Close window
(Log off)
