ASSEMBLY PLATFORM Owner's manual

The Cencorp 1300 FA cell is a heavy duty
producon plaorm with standard operang
soware and graphical user inteface. This
exible plaorm can easily be congured
for a wide range of light assembly and
part handling applicaons in both high
volumelow mix and in low volume–high mix
environments. By starng with a proven
plaorm, custom soluons are delivered wit
lower cost, less technical risk, and shorter
delivery me when compared to ground-up
automaon development.
Equipped with state-of theart industrial
robots, the 1300 FA meets the most
demanding requirements for speed and
accuracy. Three dierent robot arms are
available depending on the applicaon need.
All the robots are roof mounted allowing
a large working area for the ulizaon of
process heads, applicaon units, feeders and
transport systems.
The 1300 FA has been designed for heavy
24/7 ulizaon. This workhorse system allows
Cencorp customers to improve manufacturing
compeveness through increased capacity,
Applicaon Experts
Flexible Plaorm
Process specic applicaons are built using
Cencorp’s huge applicaon module library
and by integrang process units from 3rd
party experts. The 1300 FA can be congued
both as an stand-alone process unit or linked
together with conveyors in a turnkey assembly
line. By using proven process modules and a
standard plaorm, Cencorp is able to deliver
cusomized soluons with minimal technal risk
and maximum ROI. Thirty years experience and
experse in automaon, assembly processes,
and manufacturing strategies, makes Cencorp a
valued partner for our customers. With more than
30 years of experience with automaon in the
electronics assembly and other related industries,
Cencorp is your trusted partner for automated
assembly and part handling soluons.
• Conveyor modules - pallet, pcb, tray, at-belt
• Grippers - servo, pneumc, vacuum
• Laser systems - marking, welding, cung
• Feeders – tube, tray, bowl, tape-and-reel
• Screw driving
• Dispensing
• Vision inspecon
• Box handling and packing
Applicaon Library (paral list) Developing new products?
Automaon is not always easy and straight forward.
Excellent results can however be achieved when
automaon is considered early during the R&D
phase. Cencorp oers DFA (design for automaon)
consulng services as an added benet to our
customers. With a collaborave eort, automaon
projects are handled so that our customer’s success
is guaranteed.
RS4-551 Spider Robots
Playload
Applicaons
Typical Processes
C3-A601 6-axis G6-551 Scara
Nominal 1kg, max 3kg
All fast processes with vercal
assembly and part handling direcons
Light assembly
Sorng
Nominal 1kg, max 3kg
Used to achieve more exibility with-
out adding product specic modules
Complex assembly
Glue dispensing (complex paerns)
Nominal 3kg, max 6kg
Used when product weight
exceeds RS4 payload
Medium weight part handling
and assembly
Test handling
Packing
Part handling where rotaon is
required
Screw driving
reduced labor, improved quality and producon
control. When combined with Cencorp line control
soware, Cencorp producon lines are capable of
true “lot size of one” exible producon.
