Assembly Drawing & Parts User guide

Item # Part # Part Description Qty Item # Part # Part Description Qty
1 Transformer Assembly 8 Control Valve Assembly
E11424 Transformer, 120V Primary, 24V Secondary 1 P21224 3 Way Poppet Solenoid Valve, 24 VDC, 3
D81614 Spade Lug, 16-14 AWG #8 2 P14018 Legris 1/8 NPT x 1/4 PI-EL-SW 2
F63238 Screw, Pan Phillips Machine, 6-32 x 3/8 ZP 2 P00535 1/8 NPT x 5/32 PI Swivel Elbow - Legris 4
F63260 Nut, Lock Washer, 6-32 Kep ZP 2 P00018 1/8 NPT Brass Muffler/Breather 3
P53218 Tubing, 5/32 OD x 3/32 ID Black Polyethelene 48"
2 Control Board Assembly P53118 Tubing, 5/32 OD x 3/32 ID Natural Polyethelene 44"
E21024 EL-21 Solid State Control Board 1 S12043 Spiral Wrap, 1/2" Black Polyethelene 32"
E21016 Terminal Strip, 16 Pin 1 F63212 Screw, Flat Hd Phillips, Machine, 6-32 x 2-1/2 ZP 2
H00015 Circuit Board Support 3 F63260 Nut, Lock Washer, 6-32 Kep ZP 2
E22708 Wire, 22AWG, 2 Strand, Grey Jacketed 22"
E22708 Wire, 22AWG, 2 Strand, Grey Jacketed 32" 9 D01531 Panel Nut, Metal 1
E22708 Wire, 22AWG, 2 Strand, Grey Jacketed 54"
10 Control Panel Enclosure Assembly
3 H30843 Plate, Power Switch On/Off 1 M21014 Control Panel Enclosure, 14 GA Egalv 1
F14212 Carriage Screw, 1/4-20 x 1/2 ZP 2
4 F75702 Nut, Power Switch Mounting 1 F01420 Nut, Nylon Lock, 1/4-20 ZP 2
E21143 Power Cord, 14-3 SJT w/ 3 Prong Plug 1
5 E75762 Switch, Power, 30 A, 125 VAC 1 D81614 Spade Lug, Vinyl, 16-14 AWG # 8 3
6 Regulator Assembly 11 Motor Power Outlet Assembly
P14113 Regulator, Parker, 1/4 NPT, 0-125 PSI 1 E00000 Outlet, Duplex 1
P12447 1/4 x 5/32 PI Swivel Elbow 1 E96184 Wire. 20AWG Stranded, Green 10"
P25421 Nipple, 1/8 NPT Hex Close 1 E96183 Wire, 14AWG Stranded, Red 10"
P18230 Fitting, 1/8M x 1/8 Barb, White Nylon Elbow 1 F63238 Screw, Pan Phillips Machine, 6-32 x 3/8 ZP 2
P01418 Tubing, 1/4 OD x 1/8 ID, Black Polyurethane 6" F63260 Nut, Lock, 6-32 Kep ZP 2
P53202 Tubing, 5/32 OD x 3/32 ID Black Polyethelene 6"
P53293 Tubing, 5/32 OD x 3/32 ID Clear Polyethelene 6" 12 Slot Cover Assembly
M00130 Back Plate Slot Cover 1
7 Router Speed Control Assembly S11436 Tape, PVC Foam S/A 1-1/4" 6"
P00117 Valve, Flow Control, SMC NAS-2000-N01 1 F63210 Screw, Pan Phillips Machine, 6-32 x 1/2 ZP 4
P00535 1/8 NPT x 5/32 PI Swivel Elbow 1 F63260 Nut, Lock, 6-32 Kep ZP 4
P53202 Tubing, 5/32 OD x 3/32 ID Black Polyethelene 6"
CASE ASSEMBLY - Drawing 4 of 4
CASTLE, INC. TSM-21 OWNERS MANUAL - PARTS LIST SERIAL # 64324 and Above
