Assembly Drawing & Parts User guide

Item # Part # Part Description Qty Item # Part # Part Description Qty

14 Rear Door Assembly 19 Clevis Bracket Assembly

M21012 Rear Door, Black 1 D07111 Clevis Bracket, 1/4" ZP BP11-C 1

F02014 Washer, 1/4 ID x 2 OD, ZP 1 D14078 Clevis Pin, 1/4 x 7/8 ZP 1

F14212 Carriage Screw, 1/4-20 x 1/2 ZP 1 D14934 Hairpin, 1/4 ZP 1

F01420 Nut, Nylon Lock, 1/4-20 ZP 1 F14585 Screw, Hex Head Cap, 1/4-20 x 5/8 ZP 2

S21002 Label, Wiring Diagram 1 F01420 Nut, Nylon Lock, 1/4-20 ZP 2

F01410 Washer, 1/4 SAE ZP 2

15 C00015 Door Handle Assembly 2

H00141 Bar Knob, Black Plastic, 1/4-20 1 20 C21006 Work Top Assembly

N00101 Spring Door Clip 1 V21001 Top, 1" Particle Board, 15" x 31", Standard Grey 1

F14125 Screw, Hex Head Cap, 1/4-20 x 1/2 ZP 1 H11402 T-Band, 1-1/4" Black Solid Convex 90"

F44134 Screw, Flat Head Socket Cap, 1/4-20 x 1-3/4 Bk Ox 4

16 C21101 Safety Switch Blade Assembly F01420 Nut, Nylon Lock, 1/4-20 ZP 4

M21016 Safety Switch Blade 1

F10327 Screw, Button Head Socket, 10-32 x 7/8 Bk Oxide 2 21 Bar Spring Assembly

N21366 Single Coil Torsion Bar Spring 1

17 Router Stop Plate Assembly M21066 Plate, Bar Spring Retainer, Egalv 1

G21007 Router Stop Plate, Black 1 F14340 Carriage Screw, 1/4-20 x 3/4 ZP 2

F14340 Carriage Screw, 1/4-20 x 3/4 ZP 1 F01420 Nut, Nylon Lock, 1/4-20 ZP 2

F01420 Nut, Nylon Lock, 1/4-20 ZP 1

F01410 Washer, 1/4 SAE ZP 1 22 Safety Switch Assembly

E10850

ctuator, Magnetic 1

18 Router Stop Switch Assembly E10850 Switch, Magnetic Reed 1

E10850

ctuator, Magnetic 1 F08112 Screw, Flat Head Phillips Machine, 8-32 x 1-1/2 ZP 4

E10850 Switch, Magnetic Reed 1 H38507 Spacer, White Nylon, 3/8 OD x 5/32 ID x 7/8 L 4

F08012 Screw, Pan Phillips Machine, 8-32 x 1/2 ZP 4 F08032 Nut, Nylon Lock, 8-32 ZP 4

F08032 Nut, Nylon Lock, 8-32 ZP 4

23 Drill Stop Switch Assembly

E10850

ctuator, Magnetic 1

E10850 Switch, Magnetic Reed 1

F08322 Screw, Flat Head Phillips Machine, 8-32 x 1/2 ZP 4

F08032 Nut, Nylon Lock, 8-32 ZP 4

CASE ASSEMBLY - Drawing 3 of 4

CASTLE, INC. TSM-21 OWNERS MANUAL - PARTS LIST SERIAL # 64324 and Above
