Assembly Drawing & Parts User guide

Item # Part # Part Description Qty Item # Part # Part Description Qty

1 Clamp Cylinder 7 Case Left Side Assembly

P00215 Cylinder, Spring Return, 2" Bore, 1.5" Stroke, SS Rod 1 G21003 Case Left Side, Green 1

P14414 Fitting, 1/4 NPT x 1/4 Push in Elbow 1 F14212 Carriage Screw, 1/4-20 x 1/2 ZP 2

F01420 Nut, Nylon Lock, 1/4-20 ZP 2

2 H10138 Washer, Fiber, 1-3/8 ID 1 S00320 Label. Serial Number 1

3 Clamp Guard 8 Dust Hole Cover

M00210 Clamp Guard, Yellow 1 M21009 Dust Hole Cover 1

F14234 Carriage Bolt, 1/4-20 x 1-3/4 ZP 1 F87192 Screw, Pan Phillips Machine, 8-23 x 3/8 Thrd Cutting 3

F14478 Screw, Skt Hd Cap Screw, 1/4-20 x 7/8 Bk Oxide 2

F14202 Nut, Pem Self Clinching, 1/4-20 #2 2 9 M00400 Door, Front, Black W/ Logo 1

F01410 Washer, 1/4 SAE ZP 2

F01420 Nut, Nylon Lock, 1/4-20 ZP 3 10 Door Hinge Assembly 2

D00720 Hinge, Plastic, Black, Female 2

4 F11412 Nut, Hex Jam 1-1/4-12 ZP 1 F10010 #12X1/2 Self Tapping SMS 4

5 C00200 Clamp Foot Assembly 11 Case Hinge Assembly 2

N21351 Clamp Foot, Small Zinc Plated 1 D00710 Hinge, Plastic, Black, Male 2

N70118 Pad, Polyurethane 1-1/8" 1 F10010 #12X1/2 Self Tapping SMS 4

F12222 Nut, Hex Jam, 1/2-20 ZP 1

12 Case Bottom Assembly

6 Case Top Assembly G21001 Case Bottom, Green 1

G21002 Case Top, Green 1 F14212 Carriage Screw, 1/4-20 x 1/2 ZP 4

F14212 Carriage Screw, 1/4-20 x 1/2 ZP 4 F01420 Nut, Nylon Lock, 1/4-20 ZP 4

F14234 Carriage Bolt, 1/4-20 x 1-3/4 ZP 1 F38034 Carriage Screw, 3/8-16 x 3/4 ZP 3

F01420 Nut, Nylon Lock, 1/4-20 ZP 5 F38160 Nut, Nylon Lock, 3/8-16 ZP 3

F08012 Screw, Pan Phillips Machine, 8-32 x 1/2 ZP 1 F12120 Washer, 1/2 SAE ZP 2

F08032 Nut, Nylon Lock, 8-32 ZP 1

D08320 Cable Tie Holder, Small White, Nylon 1 13 Case Right Side Assembly

S21001 Label, TSM-21 Model Number 1 G21004 Case Right Side 1

S00301 Label, Warning, Keep Hands Clear, Lexan 1 F14212 Carriage Screw, 1/4-20 x 1/2 ZP 2

S11635 Label, Made in USA 1 F01420 Nut, Nylon Lock, 1/4-20 ZP 2

S17578 Label, Caution, "Wear Safety Glasses" 1

CASE ASSEMBLY - Drawing 3 of 4

CASTLE, INC. TSM-21 OWNERS MANUAL - PARTS LIST SERIAL # 64324 and Above
