Assembly Drawing & Parts User guide

Item # Part # Part Description Qty Item # Part # Part Description Qty
1 E21610 Drill Motor, Bosch PR10E 1.0 HP Motor 19 Bearing Jack Assembly
M21044 Bearing Jack, ZP 2
2 B00964 Castle Drill Bit, 9/64 Cobalt w/ 1/4" Shank 1 F14340 Carriage Screw, 1/4-20 x 3/4 ZP 4
F01420 Nut, Nylon Lock, 1/4-20 ZP 4
3 B00338 Solid Carbide 3/8" Three Flue Router Bit 1
10 H00141 Bar Knob, Black Plastic, 1/4-20 2
4 D21638 Collet Assembly, 3/8 Bosch 1
11 Drill Motor U-Bolt Assembly
5 E21617 Router Motor, Bosch 1617 2 HP Motor 1 N21143 TSM-21 Trimmer U-Bolt 1
F01410 1/4 SAE Flat Washer 2
6 Motor Mount U-Bolt Assembly F01420 1/4-20 Nylon Insert Locknut 1
N21142 Motor Mount U-Bolt, 1/4-20 ZP 1
F01420 Nut, Nylon Lock, 1/4-20 ZP 1 12 Motor Carriage Assembly
F01410 Washer, 1/4 SAE ZP 1 G21123 Motor Carriage Weldment 1
N03442 Bushing, 3/4" Hex Carriage Pivot, Brass 2
7 C21004 Drive Cylinder Assembly F14458 Screw, Cup Point Socket Set, 1/4-20 x 1-1/4 2
P21306 Cylinder, 1.06 Bore x 3" Stroke, SS Rod 1 F01420 Nut, Nylon Lock, 1/4-20 ZP 2
D07130 Rod Clevis, 1/4" 1
D14034 Clevis Pin, 1/4 x 3/4 ZP 1 13 Foot Switch Assembly
D14934 Hairpin, 1/4 ZP 1 E00491 Switch, Foot Activated, Linemaster 491-SC36 w/Cord 1
F51620 Nut, Jam, 5/16-24 ZP 1 M00235 Guard, Castle Universal Footswitch 1
P00535 1/8 NPT x 5/32 PI Swivel Elbow 2 F40388 Screw, Oval Head Self-Tapping, #4 x 3/8 SS 2
8 Extension Spring Assembly
H25061 Spring, Extension, .562 OD x 8.25 L x .062 Dia. ZP 1
D14100 Clevis Pin, 1/4 x 1 1
CASE ASSEMBLY - Drawing 2 of 4
CASTLE, INC. TSM-21 OWNERS MANUAL - PARTS LIST
SERIAL # 64324 and Above
