CASE ASSEMBLY - Drawing 2 of 4 Item # Part # 1 E21610 Part Description Qty Drill Motor, Bosch PR10E 1.
CASE ASSEMBLY - Drawing 3 of 4 Item # Part # Part Description Qty P00215 P14414 Clamp Cylinder Cylinder, Spring Return, 2" Bore, 1.
CASE ASSEMBLY - Drawing 3 of 4 Item # Part # Part Description Qty M21012 F02014 F14212 F01420 S21002 Rear Door Assembly Rear Door, Black Washer, 1/4 ID x 2 OD, ZP Carriage Screw, 1/4-20 x 1/2 ZP Nut, Nylon Lock, 1/4-20 ZP Label, Wiring Diagram 1 1 1 1 1 C00015 H00141 N00101 F14125 Door Handle Assembly Bar Knob, Black Plastic, 1/4-20 Spring Door Clip Screw, Hex Head Cap, 1/4-20 x 1/2 ZP 2 1 1 1 C21101 M21016 F10327 Safety Switch Blade Assembly Safety Switch Blade Screw, Button Head Socket, 10-32 x
CASE ASSEMBLY - Drawing 4 of 4 Item # Part # Part Description Qty E11424 D81614 F63238 F63260 Transformer Assembly Transformer, 120V Primary, 24V Secondary Spade Lug, 16-14 AWG #8 Screw, Pan Phillips Machine, 6-32 x 3/8 ZP Nut, Lock Washer, 6-32 Kep ZP 1 2 2 2 E21024 E21016 H00015 E22708 E22708 E22708 Control Board Assembly EL-21 Solid State Control Board Terminal Strip, 16 Pin Circuit Board Support Wire, 22AWG, 2 Strand, Grey Jacketed Wire, 22AWG, 2 Strand, Grey Jacketed Wire, 22AWG, 2 Strand, Grey
