6 Using Setup Memory
Creating Data Logger setup data using the Setup Wizard or Advanced Setup causes the
data to be stored in the “current setup memory area”. The current contents of the current
setup memory area are overwritten whenever you create other setup data.
You can use setup memory to save the current setup memory area contents to calculator
memory to keep it from being overwritten, if you want.
k Saving a Setup
A setup can be saved when any one of the following conditions exist.
• After configuring a new setup with Setup Wizard
See step 8 under “To configure a Data Logger setup using Setup Wizard” on page 2-2.
• After configuring a new setup with Advanced Setup
See step 6 under “To configure a Data Logger setup using Advanced Setup” on page 3-1
for more information.
• While the E-CON3 main menu (page 1-1) is on the display
Performing the setup save operation while the E-CON3 main menu is on the display saves
the contents of the current setup memory area (which were configured using Setup Wizard
or Advanced Setup).
Details on saving a setup are listed below.
u
To save a setup
1. If the final Setup Wizard screen is on the display, advance to step 2. If it isn’t, start the
save operation by performing one of the function key operations described below.
 If the Advanced Setup menu (page 3-1) is on the display, press 3(MEM).
 If the E-CON3 main menu (page 1-1) is on the display, press 2(MEM).
• Performing any one of the above operations causes the setup memory list to appear.
• The message “No Setup-MEM” appears if setup memory is empty.
6-1
