3. Perform one of the following operations, in accordance with the trigger source that was
selected in step 2.
If this is the trigger
source:
Do this next:
[EXE] key
Press w to finalize Trigger Setup and return to the Advanced
Setup menu.
Count Down Specify the countdown start time. See “To specify the
countdown start time” below.
CH1 Specify the trigger threshold value and trigger edge direction.
See “To specify the trigger threshold value and trigger edge
type”, “To configure trigger threshold, trigger start edge, and
trigger end edge settings” on page 3-11 or “To configure
Photogate trigger start and end settings” on page 3-12.
SONIC Specify the trigger threshold value and motion sensor level.
See “To specify the trigger threshold value and motion sensor
level” on page 3-12.
Mic Specify microphone sensitivity. See “To specify microphone
sensitivity” below.
[START] key
Press w to finalize Trigger Setup and return to the Advanced
Setup menu.
u
To specify the countdown start time
1. Move the highlighting to “Timer”.
2. Press 1(Time) to display a dialog box for specifying the countdown start time.
3. Input a value in seconds from 1 to 10.
4. Press w to finalize Trigger Setup and return to the Advanced Setup menu.
u
To specify microphone sensitivity
1. Move the highlighting to “Sense” and then press one of the function keys describe below.
To select this level of microphone sensitivity: Press this key:
Low
1(Low)
Medium
2(Mid)
High
3(High)
2. Press w to finalize Trigger Setup and return to the Advanced Setup menu (page 3-1).
3-10
Using Advanced Setup
