User Manual

General Guide
EN-5
English
Bottom
Rear
Pedal connector
DC 24V terminal
USB port
LINE OUT R, L/MONO jacks
LINE IN R, L/MONO jacks MIDI OUT/IN
terminals
Power lamp
PHONES jacks
Front
When playing the Digital Piano, make sure that the
cover is fully opened.
*
CAUTION
• Note the points below whenever opening or closing
the keyboard cover to avoid pinching your fingers or
the fingers of others between the cover and
keyboard. Particular care is required when children
are present.
– Do not let go of the cover while opening or closing
it.
– When closing the cover, do not press down on its
top with your hand. (Doing so creates the risk of
pinching your hand between the folding panels.)
– Do not play on the keyboard while the cover
incompletely opened.
1. Holding the handles on the front of the cover
with both hands, carefully lift it upwards.
2. Carefully push the cover into back towards
the piano so it folds completely out of the
way.
1. Holding the handles on the front of the cover
with both hands, carefully pull it towards you.
2. Carefully lower the cover into place.
Keyboard Cover
To open the keyboard cover
To close the keyboard cover
