Specifications

— 2 —
Exposure Control Metering: Multi-pattern by imaging element
Exposure: Program AE
Exposure Compensation: –2EV to +2EV (in 1/3EV steps)
Shutter CCD shutter, mechanical shutter
1/4 to 1/8000 second
Aperture F2.5 fixed
White Balance Automatic/fixed (4 modes) /Manual
Self-timer 10 seconds
Built-in Flash Flash Modes: Auto, Off, On, Red-eye reduction
Approximate Flash Range: 1 meter to 2 meters
Recording Functions Snapshot (with audio for EX-M1 only); self-timer; Night Scene; Movie (with audio for EX-M1
only); voice recording (EX-M1 only)
* Audio is monaural
Audio Recording Time Audio Snapshot: Approximately 30 seconds maximum per image
(EX-M1 only) Voice Recording: Approximately 50 minutes with built-in memory
After Recording: Approximately 30 seconds maximum per image
Monitor Screen 1.6-inch TFT color LCD
84,960 pixels (354 x 240)
Viewfinder Monitor screen and optical viewfinder
Timekeeping Functions Built-in quartz digital clock
Date and Time: Recorded with image data
Auto Calendar: To 2049
Input/Output Terminals Cradle connector
(EX-M1 connector is also used for connection of remote controller.)
Speaker (EX-M1 only) 20mm round, monaural
Audio Player Function Data Compression/Decompression: MP3 (MPEG-1 Audio Layer-3)
(EX-M1 Only) Sampling Frequencies: 32kHz, 44.1kHz, 48kHz
Bit Rates: 32 to 210 kbps, VBR-compatible
Play Mode: Normal, all track repeat, 1-track repeat
Practical Maximum Headphone Output: 9mW + 9mW (16 Ω)
Power Supply Power Requirements: Rechargeable lithium ion battery (NP-20) x 1
Approximate Battery Life:
The values noted above are approximate values until power fails, based on continuous recording with flash off, at normal
temperature (25°C). The above does not guarantee that you will be able to achieve this level of operation. Low temperatures
shorten battery life. Voice recording times are based on continuous recording, while audio playback times are based on
continuous output (through headphones).
* Voice recording and audio playback times apply to the EX-M1 only.
Power Consumption DC 3.7V Approximately 3.0W
Continuous Recording
Continuous Playback (Continuous Snapshot Recording)
Continuous Voice Recording*
Continuous Audio Playback*
80 minutes (480 shots)
110 minutes
80 minutes
330 minutes
