E Digital Camera User’s Guide Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.
Unpacking As you unpack your camera, check to make sure that all items shown below are included. If anything is missing, contact your original retailer. Digital camera Rechargeable lithium ion battery (NP-60) Charger unit (BC-60L) To attach the strap to the camera Attach strap here. * The shape of the power cord plug varies according to country or geographic area.
Read this first! • The contents of this manual are subject to change without notice. • The contents of this manual have been checked at each step of the production process. Feel free to contact us if you notice anything that is questionable, erroneous, etc. • Any copying of the contents of this User’s Guide, either in part or its entirety, is forbidden. Except for your own personal use, any other use of the contents of this manual without the permission of CASIO COMPUTER CO., LTD.
Contents Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Read this first! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . General Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Monitor Screen Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... 2 ... 3 ... 9 . .
❚❙ Recording Movies 55 To record a movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 ❚ Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Recording a High-definition Movie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Recording a High Speed Movie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Using Prerecord Movie . . . . . . . . . . . . . . . . . . .
❚ ❚ ❚ ❚ ❚ ❚ ❚ Specifying the Metering Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .(Metering) . . . Optimizing Image Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Lighting) . . . Specifying Flash Intensity . . . . . . . . . . . . . . . . . . . . . . . . . (Flash Intensity) . . . Using Built-in Color Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Color Filter) . . . Controlling Image Sharpness . . . . . . . . . . . . . . . . . . . . . . . . . .
❚ ❚ ❚ ❚ ❚ Playing Movies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Uploading Movie Files to YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Viewing User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . (PDF Files) . . Transferring Images from Your Computer to Camera Memory. . . . . . . . . . . . . User Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
❚ To replace the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163 ❚ Battery Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163 ❚ Using the Camera in another Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164 Using a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164 ❚ To replace the memory card . . . . . . . . . . . . . . . . . . .
General Guide The numbers in parentheses indicate the pages where each item is explained. .
Bottom coBattery/memory card slots (pages 17, 163) cpTripod hole Use this hole when attaching to a tripod. cp co .
Monitor Screen Contents The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes. They do not represent screens that actually appear on the camera. .
. Movie Recording 12 3 4 5 6 1Recording mode (page 55) 2Audio recording disabled (page 58) 3Remaining movie memory capacity (page 177) 4Movie recording time (page 55) 5Movie recording in progress (page 55) 6 Movie quality (HD/STD movie) (pages 55, 57)/ Recording speed (high speed movie) (page 58) .
. Movie Playback 12 3 4 5 6 7 9 8 1No audio data available 2File type 3Protect indicator (page 111) 4Folder name/file name (page 141) 5Movie recording time (page 94) 6Movie quality/speed (pages 55, 57, 58) 7YouTube (page 61) 8Date/time (page 148) 9Battery level indicator (page 18) .
Quick Start Basics What is a digital camera? A digital camera stores images on a memory card, so you can record and delete them a countless number of times. Record Play Delete You can use the images you record in a variety of different ways. Store images on your computer. Print images. 14 Attach images to e-mail.
What you can do with your CASIO camera Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following three main functions. High Speed CS/Prerecord CS Now you can shoot continuous high-resolution images at the amazing speed of 30 images per second. Prerecord CS pre-records images to ensure you are almost never too late with the shutter button. See page 48 for more information.
First, charge the battery prior to use. Note that the battery of a newly purchased camera is not charged. Perform the steps under “To charge the battery” to bring the battery to a full charge. • Your camera requires a special CASIO rechargeable lithium ion battery (NP-60) for power. Never try to use any other type of battery. To charge the battery 1. Positioning the positive + and negative - terminals of the battery with those of the charger unit, load the battery into the charger unit. 2.
Other Charging Precautions • Use the special charger (BC-60L) to charge the special lithium ion battery (NP-60). Never use any other type of charger device. Attempting to use a different charger can result in unexpected accident. • A battery that is still warm due to normal use may not charge fully. Give the battery time to cool before charging it. • A battery discharges slightly even when it is not loaded in the camera.
3. Close the battery cover. 2 Close the battery cover and then shift the slider towards LOCK. • For information about how to replace the battery, see page 163. 1 Checking Remaining Battery Power As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below. Remaining Power High Battery Indicator Indicator Color Cyan Low * * * Amber * * Red * Red indicates battery power is low. Charge the battery as soon as possible.
Configuring Basic Settings the First Time You Turn On the Camera The first time you load a battery into the camera, a screen appears for configuring the display language, date, and time settings. Failure to set the date and time correctly will cause the wrong date and time data to be recorded with images. IMPORTANT! • A screen for language selection will not appear in step 2 of the procedure below if you purchased a camera intended for the Japanese market.
NOTE • Each country controls its local time offset and the use of summer time, and so they are subject to change. • Removing the battery from the camera too soon after configuring time and date settings for the first time can cause the settings to be reset to their factory defaults. Do not remove the battery for at least 24 hours after configuring settings.
To load a memory card 1. Press [ON/OFF] to turn off the camera and then open the battery cover. 1 Slide the battery cover slider towards OPEN and then open it as indicated by the arrows in the illustration. 2. 2 Load a memory card. Positioning the memory card so its front is facing upwards (towards the monitor screen side of the camera), slide it into the card slot all the way in until you hear it click securely into place. Front Front 3. Close the battery cover.
To format (initialize) a new memory card You need to format a new memory card before using it for the first time. 1. Turn on the camera and press [MENU]. 2. On the “Set Up” tab, select “Format” and then press [6]. 3. Use [8] and [2] to select “Format” and then press [SET]. IMPORTANT! • Formatting a memory card that already has snapshots or other files on it, will delete its contents. Normally you do not need to format a memory card again.
Turning the Camera On and Off To turn power on To enter the REC mode, press [ON/OFF] (Power) or [r] (REC). To enter the PLAY mode, press [p] (PLAY). The back lamp will light (green) momentarily and the camera will turn on. • Pressing [p] (PLAY) while in the REC mode switches to the PLAY mode. • The Sleep function or Auto Power Off (pages 149, 149) will turn off power automatically if you do not perform any operation for a preset amount of time.
To shoot a snapshot The following procedure describes how to shoot a single snapshot. For information about shooting a series of shots (Continuous Shutter), see page 47. 1. Press [r] (REC) to turn on the camera. Make sure R (Auto) is on the display. If it isn’t, see page 63. Auto icon Monitor screen Shutter button [r] (REC) Remaining snapshot memory capacity (page 176) 2. Point the camera at the subject. You can zoom the image, if you want.
3. Half-press the shutter button to focus the image. When focus is complete, the camera will beep, the back lamp will light green, and the focus frame will turn green. • If the current aperture, shutter speed, ISO sensitivity, or Auto Exposure is not correct, the setting will turn orange when you half-press the shutter button. Back lamp Focus frame ISO sensitivity Aperture value Shutter speed Half-press Press lightly until the button stops.
Shooting a Movie [0] (Movie) Press [0] (Movie) to start movie recording. Press [0] (Movie) again to stop movie recording. See the following pages for details. Standard movie (STD movie): page 55 High-definition movie (HD movie): page 57 High speed movie (HS movie): page 58 . Using Quick Shutter Fully pressing the shutting button without waiting for Auto Focus to operate will record using Quick Shutter (page 88).
Holding the Camera Correctly Your images will not come out clearly if you move the camera when you press the shutter button. When pressing the shutter button, be sure to hold the camera as shown in the illustration below, and keep it still by pressing your arms firmly against your sides as you shoot. Holding the camera still, carefully press the shutter button and take care to avoid all movement as the shutter releases and for a few moments after it releases.
Viewing Snapshots Use the following procedure to view snapshots on the camera’s monitor screen. • For information about how to play back movies, see page 94. • For information about images recorded using continuous shutter (CS), see page 95. 1. Press [p] (PLAY) to enter the PLAY mode. • This will display one of the snapshots currently stored in memory. • Information about the displayed snapshot also is included (page 12).
Deleting Images If memory becomes full, you can delete images you no longer need in order to free up storage and record more images. IMPORTANT! • Remember that a file (image) delete operation cannot be undone. • For information about images recorded using continuous shutter (CS), see page 97. To delete a single file 1. Press [p] (PLAY) to enter the PLAY mode and then press [2] ( ). 2. Use [4] and [6] to scroll through the files until the one you want to delete is displayed. 3.
Snapshot Shooting Precautions Operation • Never open the battery cover while the back lamp is flashing green. Doing so can result in the image you just shot being saved incorrectly, damage to other images stored in memory, malfunction of the camera, etc. • If unwanted light is shining directly onto the lens, shade the lens with your hand. Monitor Screen when Shooting Snapshots • Subject brightness conditions can cause monitor screen response to slow and can cause digital noise in the monitor screen image.
Snapshot Tutorial Using the Control Panel The control panel can be used to configure camera settings. 1. In the REC mode, press [SET]. 2. Use [8] and [2] to select the setting you want to change. [8] [2] [4] [6] This will select one of the control panel icons and display its settings.
Changing the Image Size (Size) . Pixels A digital camera image is a collection of small dots called “pixels”. The more pixels there are in an image, the more detail there will be. However, you generally can do with fewer pixels when printing an image (L size) through a print service, attaching an image to e-mail, when viewing the image on a computer, etc. Pixel . About image sizes The size of an image indicates how many pixels it contains, and is expressed as horizontal pixelsxvertical pixels.
Image Size Selection Tips Note that larger images have more pixels, so they take up more memory space. Large Number of Pixels More detail, but takes up more memory. Best when you plan to print large-size prints (such as A3 size). Small Number of Pixels Less detail, but takes up less memory. Best when you want to send images by e-mail, etc. • For information about image size, image quality, and number of images that can be stored, see page 176. • For information about movie image size, see page 91.
Image Size (Pixels) Suggested Print Size and Application Description 9M A3 Print (3456x2592) 3:2 A3 Print (3456x2304) Good detail for better clarity even for images cropped (page 115) from the original 16:9 HDTV (3456x1944) 6M A3 Print (2816x2112) 4M A4 Print (2304x1728) Good detail 2M 3.5"x5" Print (1600x1200) Best when preserving memory capacity is relatively more important than image quality. VGA (640x480) Image files are smaller, which is better when attaching images to e-mail.
Specifying ISO Sensitivity (ISO) ISO sensitivity is a measure of sensitivity to light. 1. In the REC mode, press [SET]. 2. Use [8] and [2] to select the second control panel option from the top (ISO Sensitivity). 3. Use [4] and [6] to select the setting you want and then press [SET]. AUTO Adjusts sensitivity automatically according to conditions ISO 100 Lower sensitivity ISO 200 Slow shutter speed Less noise Fast shutter speed (Set for shooting in dimly lit areas.
3. Use [4] and [6] to select the shooting condition you want and then press [SET]. ‡ Auto WB Configures the camera to adjust white balance automatically ¤ Daylight For shooting outdoors on a clear day ' Overcast For shooting outdoors on an overcast rainy day, in the shade, etc.
Correcting Image Brightness (EV Shift) You can manually adjust an image’s exposure value (EV value) before shooting it. • Exposure Compensation Range: –2.0EV to +2.0EV • Unit: 1/3EV 1. In the REC mode, press [SET]. 2. Use [8] and [2] to select the fourth control panel option from the top (EV Shift). 3. Use [4] and [6] to adjust the exposure compensation value. [6]: Increases the EV value. A higher EV value is best for light-colored subjects and backlit subjects. [4]: Decreases the EV value.
Shooting with Slow Motion View When you press [SLOW] (Slow Motion View), the camera will start to pre-record images continually in a buffer and play them back at slow speed. Up to three seconds worth of pre-recorded images are in the buffer. Fully pressing the shutter button will save the currently displayed pre-recorded image. You can specify one of eight playback speeds for prerecorded images. [SLOW] (Slow Motion View) . To get ready to shoot with Slow Motion View 1. In the REC mode, press [SET]. 2.
. To shoot with Slow Motion View 1. Point the camera at the subject. 2. Press [SLOW] (Slow Motion View). This will start slow motion playback of pre-recorded images on the monitor screen. • You can use [4] and [6] to change the playback speed while Slow Motion View playback is in progress. 3. When the pre-recorded image you want to save is displayed, press the shutter button. Playback speed bar This will store the displayed image as a snapshot and exit Show Motion View.
Using Lag Correction (Lag Correction) The Lag Correction function lets you correct for the lag time from the point you decide to shoot until the point it takes for the shutter to actually release. This feature actually does not speed up shutter release, but instead it pre-records images when you halfpress the shutter button and saves what occurred slightly before you press the shutter button. 1. In the REC mode, press [SET]. 2.
NOTE • Lag Correction will not be performed if you press the shutter button all the way without first pressing it half way. • If the camera’s image size setting is 9M, 3:2, or 16:9 when you shoot with Lag Correction, the size of the resulting image will be 6M. • The shooting range of Lag Correction is narrower than that of the Single Shot mode. • The lag correction time you should select depends on a variety of factors.
Using Flash (Flash) 1. In the REC mode, press [2] ( ) once. 2. Use [4] and [6] to select the flash setting you want and then press [SET]. 3. Flash [2] ( ) > Auto Flash Flash fires automatically in accordance with exposure (amount of light and brightness) conditions. ? Flash Off Flash does not fire. < Flash On Flash always fires. This setting can be used to brighten a subject that normally comes out dark due to daylight or backlight (daylight synchro flash).
NOTE • Take care so your fingers and the strap do not block the flash. • The desired effect may not be obtained when the subject is too far away or too close. • Flash charging time (page 180) depends on operating conditions (battery condition, ambient temperature, etc.). • Shooting with flash turned off when lighting is dim results in a slow shutter speed, which can cause image blur due to camera movement. Under such conditions, secure the camera with a tripod, etc.
Changing the Control Panel Date/Time Style 1. In the REC mode, press [SET]. 2. Use [8] and [2] to select the bottom control panel option (Date/Time). You can use [4] and [6] to select date or time display. NOTE • You can select either of two display styles (page 148) for the date: Month/Day or Day/Month. • The time is displayed using 24-hour format.
NOTE • The higher the digital zoom factor, the coarser the recorded image. Note that the camera also has a function that lets you record using digital zoom without image deterioration (page 46). • Use of a tripod is recommended to protect against image blur due to camera movement when shooting with telephoto. • Performing a zoom operation changes the lens aperture. • Both optical zoom and digital zoom are disabled during high speed movie recording.
Undeteriorated digital zoom Undeteriorated image quality range Deteriorated image quality range 3X to 16.2X 1X Optical/digital zoom switch point * 3X optical zoom point 12.0X to 47.8X Zoom pointer (Indicates current zoom.) Deterioration point • The deterioration point depends on Image Maximum Deterioration the current image size setting (page Size Zoom Factor Point 32).
Using Continuous Shutter Pressing Ç (Continuous Shutter) toggles between the Continuous Shutter mode and the Single Shot mode (page 24). Ç (Continuous Shutter) Using Normal-speed Continuous Shutter With normal-speed continuous shutter (Normal Speed CS) you can shoot a series of images at a speed of approximately one image per second as long as there is memory available for image storage. 1. In the REC mode, press [MENU]. 2. Use [4] and [6] to select the “REC” tab. 3.
Using High Speed CS and Prerecord CS With High Speed CS, you can configure the camera to shoot at a speed of 3, 5, 10, 15, or 30 images per second, as long as you keep the shutter button and there is memory available to store the images. With Prerecord CS, half-pressing the shutter button starts continual pre-recording of images to a temporary buffer.
• You can configure the mode so up to 25 images are pre-recorded to the buffer until you fully press the shutter button. • The minimum number of pre-recorded buffer images you can specify is three. Total recording time depends on the current continuous shutter frames-per-second (fps) setting. • Specifying zero for the number of pre-recorded images disables Prerecord CS and performs High Speed CS only (without pre-recording). 1. In the REC mode, press [MENU]. 2. Use [4] and [6] to select the “REC” tab.
9. Use [8] and [2] to select the sixth control panel option from the top (Max CS shots). 10. Use [4] and [6] to select the maximum number of shots for each continuous shutter operation and then press [SET]. 11. Use [8] and [2] to select the seventh control panel option from the top (Prerecord CS shots). 12. Use [4] and [6] to specify how many of the 30 images and for how long images should be pre-recorded in the buffer.
14. Half-press the shutter button. This will cause the camera to start pre-recording images. • The camera will not emit a shutter sound when you half-press the shutter button while Prerecord CS is selected. 15. When you are ready to shoot, press the shutter button the rest of the way down. This will record the images in the pre-record buffer and start recording new images in real-time. Images continue to be shot as long as you keep the shutter button depressed. 16.
Specifying the Method for Saving Continuous Shutter Images Use the procedure below to specify how images should be saved after a High Speed CS operation. 1. In the REC mode, press [MENU]. 2. Use [4] and [6] to select “REC” tab. 3. Use [8] and [2] to select “Save CS Images”, and then press [6]. 4. Use [8] and [2] to change the setting. Normal (Batch) All images that were shot are saved after the continuous shutter operation is finished.
Select & Save After continuous shutter shooting is finished, the shot images are played back at slow speed so you can select the images you want to save. • When shooting with Prerecord CS, the first image saved when you press the shutter all the way is indicated by an “S” mark so you can tell where the continuous shutter operation started. Mark 1While the shot images are playing back and an image appears that you want to save, press the shutter button.
Continuous Shutter Precautions • If there is not enough available capacity on the memory card, you may not be able to record the number of CS images indicated on the monitor screen. Make sure your memory card has sufficient remaining capacity before shooting with using continuous shutter. • With continuous shutter, exposure and focus for the first image are applied for successive images as well. • When using a continuous shutter mode, keep the camera still until shooting is finished.
Recording Movies To record a movie The following procedure explains how to record a standard (STD) movie. See the pages indicated below for more information about movies. High-definition movie (HD movie): page 57 High speed movie (HS movie): page 58 1. [0] (Movie) In the REC mode, set the movie mode switch to ³ (HD/STD). Movie mode switch 2. Press [MENU]. 3. Use [4] and [6] to select the “Quality” tab. 4. Use [8] and [2] to select “» Quality” and then press [6]. 5.
Shooting with BEST SHOT With BEST SHOT (page 63), you can select the sample scene that matches the type of movie you are trying to shoot and the camera will change its setup accordingly, for beautiful movies every time. Selecting the “Natural Green” BEST SHOT scene, for example, will shot images with vivid green trees and grass.
NOTE • Spending a long time using movie recording will cause the camera to become slightly warm to the touch. This is normal and does not indicate malfunction. • Use of certain types of memory cards slows down data transfer and increases the time it takes to record movie data, which can result in movie frames being dropped. The “0 REC” indicator on the monitor screen turns yellow to indicate that frames are being dropped.
Recording a High Speed Movie This camera supports recording of high speed movies at a maximum speed of 1000 fps. The aspect ratio of movies recorded with this mode depends on the frame rate (recording speed). • Audio is not recorded in this mode. 1. In the REC mode, set the movie mode switch to © (HS). 2. Press [MENU]. 3. Use [4] and [6] to select the “Quality” tab. 4. Use [8] and [2] to select “HS » Speed” and then press [6]. 5.
NOTE • The higher the frame rate (speed), the more lighting is required when shooting. When shooting a high speed movie, shoot in a well-lit environment. • When recording certain types of movies, the image that appears on the monitor screen may be smaller than normal. When recording a high speed movie, there are black bands along the top, bottom, left, and right of the screen. • When recording a high speed movie, light source flicker can cause horizontal bands to appear in the image.
. To set up the camera to shoot with Prerecord Movie 1. In the REC mode, select the movie mode you want to use by setting the movie mode switch to ³ (HD/STD) or © (HS). 2. Press [BS]. 3. Use [8], [2], [4], and [6] to select the “Prerecord (Movie)” scene and then press [SET]. This causes ‰ to appear on the monitor screen, indicating that the camera is prerecording to its buffer. . To shoot a Prerecord Movie 1.
Recording a Movie for YouTube (For YouTube) The “For YouTube” scene records movies in a format that is optimal for uploading to the YouTube movie site, which is operated by YouTube, LLC. “For YouTube” can be used when shooting a standard (STD) movie, a high-definition (HD) movie, or a high speed (HS) movie. 1. In the REC mode, set the movie mode switch to ³ (HD/STD) or © (HS). Select the movie mode you want to use. 2. Press [BS]. 3.
Shooting a Snapshot while Shooting a Movie 1. While a movie is being recorded, press the shutter button. Movie recording continues after the snapshot is recorded. Number of recordable snapshots NOTE • You can shoot up to 10 snapshots per movie. The number of snapshots is also limited by the amount of free space available on the memory card. • Note that the flash cannot be used when shooting a Snapshot in Movie.
Using BEST SHOT What is BEST SHOT? BEST SHOT provides you with a collection of sample “scenes” that show a variety of different types of shooting conditions. When you need to change the setup of the camera, simply find the scene that matches what you are trying to achieve, and the camera sets up for it automatically. This helps to minimize the chance of ruined images due to poor exposure and shutter speed settings.
3. Press [SET] to configure the camera with the settings for the currently selected scene. This returns to the REC mode. • The settings of the scene you selected remain in effect until you select a different scene. • To select a different BEST SHOT scene, repeat the above procedure from step 1. 4. Press the shutter button (if you are shooting a snapshot) or [0] (if you are shooting a movie). .
. BEST SHOT Precautions • BEST SHOT scene images were not shot using this camera. • Images shot using a BEST SHOT scene may not produce the results you expected due to shooting conditions and other factors. • You can modify the camera settings that are configured after you select a BEST SHOT scene. Note, however, that the BEST SHOT settings revert to their defaults when you select another BEST SHOT scene or turn off the camera.
Creating Your Own BEST SHOT Setups You can save up to 999 camera setups as user BEST SHOT scenes for instant recall whenever you need them. 1. On the BEST SHOT scene menu, select the scene named BEST SHOT (Register User Scene). 2. Use [4] and [6] to select the snapshot whose setup you want to save. 3. Use [8] and [2] to select “Save”, and then press [SET]. Your BEST SHOT scene will be assigned the name “Recall User Scene”, along with a scene number.
Shooting with High Speed Night Scene (High Speed Night Scene) With High Speed Night Scene, the camera detects automatically whether it is being hand-held or on a tripod. When you press the shutter button, the camera will record a series of images and combine them in a way that minimizes image blur due to low light conditions.
Shooting with High Speed Anti Shake (High Speed Anti Shake) When you press the shutter button while High Speed Anti Shake is enabled, the camera records multiple images and automatically combines them in a way that produces a final image with minimal blur. You can shoot with this feature to minimize the effects of camera movement when shooting with optical anti shake does not produce the desired results. 1. Press [BS] and then select “High Speed Anti Shake”. 2.
Isolating Moving Subjects (Multi-motion image) Multi-motion image can be used to isolate a moving subject within a series of multiple images and place them against a stationary background. Use a tripod or some other means to make sure that the camera is not moving or shaking when shooting with Multi-motion image. Basic Multi-motion image Procedure 1. Press [BS] and then select “Multi-motion Image”. 2. Hold down the shutter button to record. 3. Release the shutter button.
NOTE • This BEST SHOT scene saves only a single final image. • To cancel this BEST SHOT scene and enter the Continuous Shutter mode, press Ç (Continuous Shutter). • Shooting with this BEST SHOT scene makes the shooting range narrower than normal. • Shooting with “Multi-motion Image” assumes that the subject is moving and changing positions. Trying to use it to shoot a subject that is moving while maintaining the same location (such as a golf swing, a baseball swing, etc.
Shooting with Priority on Subject Faces (High Speed Best Selection) With High Speed Best Selection, the camera automatically shoots a series of images, and selects the best one based on facial image blur, and facial expression (whether the subject is smiling or blinking). 1. Press [BS] and then select the “High Speed Best Selection” scene. 2. Press the shutter button to shoot. • This will cause the message “Busy... Please wait...” to appear. Do not move the camera while this message is displayed.
Shooting an Image in Accordance with Subject Movement (Move Out CS/Move In CS) You can use these features to shoot an image automatically whenever the subject moves into or moves out of a frame on the monitor screen. You also can configure the camera to record images of what happened immediately before and after the subject moves. Move Out CS Automatically records what happened immediately before and after the subject moves outside of a boundary on the monitor screen.
7. Use [4] and [6] to select the continuous shutter (CS) speed you want and then press [SET]. CS speed AUTO The camera measures light levels and configures the fastest possible CS speed setting automatically. 3 to 30 fps Enables specification of the number of CS images recorded per second. * fps (frames per second) is a unit of measurement indicating the number of images recorded or played back per second. 8. Use [8] and [2] to select the sixth control panel option from the top (Max CS shots). 9.
13. Use [8] and [2] to select the second control panel option from the bottom (Trigger Sense). 14. Use [4] and [6] to select the subject movement sensitivity, and then press [SET]. • You can select any one of three sensitivity levels: “High”, “Normal”, or “Low”.
4. Image recording will continue until the end of the recording time is reached. • While the camera is in Move Out CS recording standby, you can cancel standby by pressing the shutter button all the way down. You then will be able to shoot images normally. • To stop an ongoing real-time recording operation, press [SET]. 5. Save the CS images (page 52). . To shoot using Move In CS 1. Compose the image at a location where you expect the subject to enter the boundary on the monitor screen. 2.
4. Image recording will continue until the end of the recording time is reached. • While the camera is in Move In CS recording standby, you can cancel standby by pressing the shutter button all the way down. You then will be able to shoot images normally. • To stop an ongoing real-time recording operation, press [SET]. 5. Save the CS images (page 52). NOTE • Compose the image so the entire subject and its background are within the boundary.
Advanced Settings The following are menu operations you can use to configure various camera settings. Using On-screen Menus . Example Menu Screen Operation Press [MENU] to display the menu screen. • Menu contents are different in the REC mode and PLAY mode. Example: REC mode menu [8] [2] [4] [6] [MENU] [SET] Menu Screen Operation Buttons [4] [6] Selects tabs. [6] is also used to display the options available for a setting. [8] [2] Selects a setting option. [SET] Registers the selected setting.
3. Use [8] and [2] to select the menu item you want, and then press [6]. 4. Use [8] and [2] to change the setting. 5. After the setting is the way you want, press [SET]. • Pressing [4] registers the selected setting and Example: When “Self-timer” is selected on the “REC” tab Tabs returns to the menu. • To configure settings on another tab after pressing [4] to return to the menu, use [8] to move the highlighting up to the tabs, and then use [4] and [6] to select the tab you want. Items .
REC Mode Settings (REC) Selecting a Focus Mode (Focus) Procedure [r] (REC) * [MENU] * REC Tab * Focus Settings Type of Shot Focus Mode Snapshot Movies Approximate Focus Range*1 Snapshot Movies Q Auto Focus General recording Automatic Approximately 40 cm to 9 (infinity) (1.3' to 9) ´ Macro Close ups Automatic Approximately 10 cm to 50 cm (3.9" to 19.
To focus with manual focus 1. On the monitor screen, compose the image so the subject you want to focus on is within the yellow boundary. 2. Watching the image on the monitor screen use [4] and [6] to adjust focus. • At this time the image that is within the boundary will enlarge and fill the monitor screen, which aids in focusing. If you do not perform any operation for two seconds while the enlarged image is displayed, the screen in step 1 will re-appear.
Using Focus Lock Subject to be focused on “Focus lock” is a technique you can use when you want to compose an image in which the subject you want to focus on is not within the focus frame in the center of the screen. • To use focus lock, select “U Spot” or “O Tracking” for the Auto Focus area (page 84). 1. Align the monitor screen’s focus frame with the subject you want to focus on and then halfpress the shutter button. 2.
Using the Self-timer (Self-timer) Procedure [r] (REC) *[MENU] * REC Tab * Self-timer With the Self-timer, pressing the shutter button starts a timer. The shutter is released and the image is shot after a fixed amount of time. „ 10 sec 10-second Self-timer ‚ 2 sec 2-second Self-timer • When shooting under conditions that slow down the shutter speed, you can use this setting to prevent image blur due to camera movement.
Reducing the Effects of Camera and Subject Movement (Anti Shake) Procedure [r] (REC) * [MENU] * REC Tab * Anti Shake You can turn on the camera’s Anti Shake feature to reduce image blur due to subject movement or camera movement when shooting a moving subject using telephoto, when shooting a fast-moving subject, or when shooting under dim lighting conditions. Auto Minimizes the effects of hand and subject movement.
Specifying the Auto Focus Area (AF Area) Procedure [r] (REC) * [MENU] * REC Tab * AF Area You can use the following procedure to change the Auto Focus metering area for shooting snapshots. • When recording movies, the AF metering area is always “U Spot”. U Spot This mode takes readings of a small area in the center of the image. This setting works well with focus lock (page 81). — Free You can move the focus frame by using [8], [2], [4], and [6] to move the focus point and then pressing [SET].
Using the Auto Focus Assist Light (AF Assist Light) Procedure [r] (REC) * [MENU] * REC Tab * AF Assist Light Half-pressing the shutter button while this setting is selected causes the front lamp to light, which provides illumination for focusing in areas where lighting is dim. Leaving this function turned off is recommended when shoot portraits from short distances, etc. Front lamp IMPORTANT! • Never look directly into the front lamp while it is lit. • Make sure your finger is not covering the front lamp.
Tips for Best Face Detection Results • The camera performs center focus if it cannot detect a face. • Always make sure that Auto Focus (AF) is selected as the focus mode when shooting with face detection. • Detection of the following types of faces is not supported. – A face that is obstructed by hair, sunglasses, a hat, etc.
Changing the Continuous Shutter Mode (CS) Procedure [r] (REC) * [MENU] * REC Tab * CS Perform the following steps to change the continuous shutter mode. É High Speed CS Z Normal Speed CS Enables shooting of up to 30 continuous shutter images at faster speeds than Normal Speed CS. Images shot with this mode cannot be any one of the following sizes: 9M, 3:2, 16:9. If the camera’s image size setting is one of these sizes, High Speed CS will shoot 6M images. See page 48 for details.
Assigning Functions to the [4] and [6] Keys (L/R Key) Procedure [r] (REC) * [MENU] * REC Tab * L/R Key You can assign one of the three functions listed below to the [4] and [6] keys.
Displaying the On-screen Grid (Grid) Procedure [r] (REC) * [MENU] * REC Tab * Grid The on-screen grid can be displayed on the REC mode monitor screen for easy vertical and horizontal alignment when composing images. Turning on Image Review (Review) Procedure [r] (REC) * [MENU] * REC Tab * Review While Review is turned on, the camera will display a image for about one second immediately after you press the shutter button to record it. • Image review is available only when shooting single images.
Configuring Power On Default Settings (Memory) Procedure [r] (REC) * [MENU] * REC Tab * Memory This setting lets you specify which camera settings should be remembered by the camera when it is turned off, and restored the next time the camera is turned on. To have the camera remember a setting, you should enable the setting’s memory. Any setting whose memory is disabled will be reset to its initial default any time the camera is turned off.
Image Quality Settings (Quality) Specifying Snapshot Image Quality (T Quality (Snapshot)) Procedure [r] (REC) * [MENU] * Quality Tab * T Quality (Snapshot) Fine Gives image quality priority Normal Normal Economy Gives the number of images priority • The “Fine” setting helps to bring out details when shooting dense tree branches or leaves, a complex pattern, etc. • Memory capacity (the number of images you can record) will be affected by the quality settings you configure (page 176).
Setting the High Speed Movie Frame Rate (HS » Speed) Procedure [r] (REC) * [MENU] * Quality Tab * HS » Speed See page 58 for details. Specifying the Metering Mode (Metering) Procedure [r] (REC) * [MENU] * Quality Tab * Metering The metering mode determines what part of the subject is metered for exposure. B Multi Multi-pattern metering divides the image into sections and measures the light in each section for a balanced exposure reading.
Specifying Flash Intensity (Flash Intensity) Procedure [r] (REC) * [MENU] * Quality Tab * Flash Intensity You can specify flash intensity to one of five levels from +2 (brightest flash) to –2 (least bright flash). • Flash intensity may not change when the subject is too far away or too close.
Viewing Snapshots and Movies Viewing Snapshots See page 28 for the procedure for viewing snapshots. Viewing a Movie 1. Press [p] (PLAY) and then use [4] and [6] to display the movie you want to view. 2. Press [SET] to start playback. Movie icon: » Recording time Image quality Movie Playback Controls Fast forward/fast reverse [4] [6] (Playback in progress.) • Each press of either button increases the speed of the fast forward or fast reverse operation. • To return to normal playback speed, press [2].
Viewing Continuous Shutter Images Each time you perform a continuous shutter (CS) operation, the camera creates a CS group that includes all of the images for that particular CS session. You can use the following procedure to play back the images in a particular CS group. 1. Press [p] (PLAY) and then use [4] and [6] to display the CS group whose images you want to view. Number of image files in the CS group CS group icon First image in the CS group 2.
The following are operations that are supported after you press [SET] to start image playback. [4] [6] During playback, changes the playback direction and playback speed. While playback is paused, scrolls forward or back. • Playback speed cannot be adjusted while the displayed image is zoomed. [SET] Toggles between pause and play. Zoom controller Zooms the image. • You can use [8], [2], [4], and [6] to scroll the zoomed image on the monitor screen. [MENU] Exits CS group playback.
Deleting Continuous Shutter Images You can use the following procedures to delete images while playback is in progress or paused. . Deleting a Specific CS Group File 1. While CS image playback is in progress or paused (toggle by pressing [SET]), press [2]. This will display the “CS Frame Edit” menu. 2. Use [8] and [2] to select “Delete” and then press [SET]. 3. Use [4] and [6] to display the image you want to delete. 4. Use [8] and [2] to select “Delete” and then press [SET].
Dividing Up a CS Group Use the following to divide up a CS Group into individual images. . Dividing Up a Specific CS Group 1. While a CS group is displayed or while the images of a CS group are scrolling on the monitor screen, press [MENU]. 2. Use [4] and [6] to select “PLAY” tab. 3. Use [8] and [2] to select “Divide Group” and then press [6]. 4. Use [4] and [6] to display the CS group folder whose CS group you want to divide up. 5. Use [8] and [2] to select “Divide” and then press [SET].
Copying a CS Group Image Use the following procedure to copy an image in a CS group to a location outside of the group. 1. While CS image playback is in progress or paused (toggle by pressing [SET]), press [2]. This will display the “CS Frame Edit” menu. 2. Use [8] and [2] to select “Copy”, and then press [SET]. 3. Use [4] and [6] to display the image you want to copy. 4. Use [8] and [2] to select “Copy”, and then press [SET].
Zooming an On-screen Image 1. In the PLAY mode, use [4] and [6] to scroll through the images until the one you want is displayed. 2. Slide the zoom controller towards z ([) to zoom. Zoom factor Image area You can use [8], [2], [4], and [6] to scroll the zoomed image on the monitor screen. Slide the zoom controller towards w to unzoom the image. – When monitor screen contents are turned on, a graphic in the lower right corner of the screen shows what part of the zoomed image is currently displayed.
Viewing Snapshots and Movies on a TV Screen 1. Use the AV cable that comes with the camera to connect it to the TV. Yellow AV cable (bundled) White USB/AV port TV Video Audio AUDIO IN jack (white) Making sure that the 6 mark on the camera is aligned with the 4 mark of the AV cable connector, connect the cable to the camera. VIDEO IN jack (yellow) • Make sure that you insert the cable connector into the USB/AV port until you feel it click securely into place.
3. Press [p] (PLAY) to turn on the camera. This will cause an image to appear on the TV screen, without anything appearing on the camera’s monitor screen. • Pressing [ON/OFF] or [r] (REC) will not turn on the camera while the AV cable is connected. • You also can change the aspect ratio of the screen and the video output system (page 151). 4. Now you can display images and play back movies as you normally do.
Other Playback Functions (PLAY) This section explains menu items that you can use to configure settings and perform other playback operations. For information about menu operations, see page 77.
Effect Select the effect you want. Pattern 1 to 5: Plays background music and applies an image change effect. • Patterns 2 through 4 have different background music, but they all use the same image change effect. • Pattern 5 can be used for playback of snapshots only (except for those that are part of a CS group), and the “Interval” setting is ignored. • Movies that include audio are played back without background music. Movies that do not include audio are played back with background music.
1. Connect the camera to your computer (pages 126, 135). If you plan to save the music files to the camera’s memory card, make sure the card is loaded in the camera. 2. Perform one of the following operations to open the memory card or built-in memory. This will cause the camera to be recognized by your computer as a Removable Disk (Drive). • Windows 1 Windows Vista: Start * Computer Windows XP: Start * My Computer Windows 2000: Double-click “My Computer”. 2 Double-click “Removable Disk”.
Creating a Snapshot of Movie Frames (MOTION PRINT) Procedure [p] (PLAY) * Movie Screen * [MENU] * PLAY Tab * MOTION PRINT 1. Use [4] and [6] to scroll through the movie frames and display the one you want to use as the image of the MOTION PRINT image. Holding down [4] or [6] scrolls at high speed. 2. 9 frames 1 frame Use [8] and [2] to select either “9 frames” or “1 frame” and then press [SET].
Editing a Movie on the Camera (Movie Editing) Procedure [p] (PLAY) * Movie Screen of Movie to be Edited * [MENU] * PLAY Tab * Movie Editing The Movie Editing feature lets you use one of the following procedures to edit out a specific part of a movie. } Cut (To-Point Cut) Cuts everything from the beginning of the movie up to the current location. ~ Cut (Point-To-Point Cut) Cuts everything between two points. ¡ Cut (From-Point Cut) Cuts everything from the current location to the end of the movie. 1.
3. Press [2] to display the editing menu and specify one or two cut points. } Cut (To-Point Cut) While the frame you want the cut to be up to is displayed, press [2]. 1While the frame you want the first (From) cut to be is ~ Cut (Point-To-Point Cut) displayed, press [2]. 2Select another frame. 3While the frame you want the second (To) cut to be is displayed, press [2]. ¡ Cut (From-Point Cut) 4. While the frame you want the cut to be from is displayed, press [2].
Adjusting White Balance (White Balance) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * White Balance You can use the white balance setting to select a light source type for a recorded image, which will affect the colors of the image. ¤ Daylight Outdoors, fair weather ' Overcast Outdoors, cloudy to rain, in tree shade, etc. “ Shade Very high temperature light, such as building shade, etc.
Adjusting the Brightness of an Existing Snapshot (Brightness) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Brightness You can select one of five brightness levels, from +2 (brightest) to –2 (least bright). NOTE • The original snapshot is retained in memory and not deleted. • When you display an altered image on the camera’s monitor screen, the date and time indicates when the image was originally recorded, not when the image was altered.
Protecting a File Against Deletion (Protect) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Protect On Protects specific files. 1 Use [4] and [6] to scroll through the files until the one you want to protect is displayed. 2 Use [8] and [2] to select “On” and then press [SET]. An image that is protected is indicated by the › icon. 3 To protect other files, repeat steps 1 and 2. To exit the protect operation, press [MENU]. To unprotect a file, select “Off” instead of “On” in step 2 above.
. To protect a specific image in a CS group 1. While CS image playback is in progress or paused (toggle by pressing [SET]), press [2]. This will display the “CS Frame Edit” menu. 2. Use [8] and [2] to select “Protect” and then press [SET]. 3. Use [4] and [6] to scroll through images until one you want to protect is displayed. 4. Use [8] and [2] to select “On” and then press [SET]. This will protect the image and display the › icon.
. To protect all the images in a CS group 1. While a CS group is displayed or while the images of a CS group are scrolling on the monitor screen, press [MENU]. 2. Use [4] and [6] to select “PLAY” tab. 3. Use [8] and [2] to select “Protect” and then press [SET]. 4. Use [4] and [6] to display the CS group you want to protect. 5. Use [8] and [2] to select “On” and then press [SET]. This will protect all the images in the group and display the › icon.
Rotating an Image (Rotation) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Rotation 1. Use [8] and [2] to select “Rotation” and then press [SET]. Each press of [SET] will rotate the displayed image 90 degrees left. 2. When the displayed image is at the orientation you want, press [MENU]. NOTE • A CS group or an image that is part of a CS group cannot be rotated. • Rotation of movie images is not supported. • Note that this procedure does not actually change the image data.
Cropping a Snapshot (Trimming) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Trimming You can crop a snapshot to trim parts you do not need, and save the result in a separate file. The original snapshot is also retained. Zoom factor Represents snapshot area Use the zoom controller to zoom the image to the size you want, use [8], [2], [4], and [6] to display the portion of the image you want to cut out, and then press [SET].
Dividing Up a Continuous Shutter Group (Divide Group) Procedure [p] (PLAY) * [MENU] * PLAY Tab * Divide Group See page 98 for details. Editing a CS Image (CS Frame Edit) Procedure [p] (PLAY) * [MENU] * PLAY Tab * CS Frame Edit See the following pages for details.
Printing Printing Snapshots Professional Print Service You can take a memory card that contains the images you want to print to a professional print service and have them printed. Printing on a Home Printer Printing Images on a Printer with Memory Card Slot You can use a printer equipped with a memory card slot to print images directly from a memory card. For details, see the user documentation that comes with your printer.
. Connecting the Camera to a Printer Use the USB cable that comes bundled with the camera to connect the camera to your printer’s USB port. USB cable Large connector USB USB/AV port USB port Small connector Making sure that the 6 mark on the camera is aligned with the 4 mark of the USB cable connector, connect the cable to the camera. • The camera does not draw power over the USB cable. Check the battery level before connecting and make sure it is not too low.
. To print 1. Turn on the printer and load paper. 2. Turn on the camera. This will display the print menu screen. 3. Use [8] and [2] to select “Paper Size”, and then press [6]. 4. Use [8] and [2] to select a paper size and then press [SET]. • The following are the available paper sizes. 3.5"x5", 5"x7", 4"x6", A4, 8.5"x11", By Printer • Selecting “By Printer” prints using a paper size selected on the printer. • See the documentation that comes with your printer for information about paper settings.
Using DPOF to Specify Images to be Printed and the Number of Copies . Digital Print Order Format (DPOF) DPOF is a standard that allows you to include image type, number of copy, and time stamp on/off information on the memory card with the images. After configuring settings, you can use the memory card to print on a home printer that supports DPOF or take the memory card to a professional print service. • Whether or not you will be able to use DPOF settings for printing depends on the printer you are using.
. Configuring the Same DPOF Settings for All the Images Procedure [p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * DPOF Printing * All images 1. Use [8] and [2] to specify the number of copies. You can specify a value up to 99. Specify 00 if you do not want to print the image. • Note that the specified number of copies will be printed for all of the images in any CS group included with the images. • If you want to include the date in the images, press [BS] so “On” is shown for date stamping. 2.
. To configure the same DPOF settings for all the images in a CS group 1. While CS image playback is in progress or paused (toggle by pressing [SET]), press [2]. This will display the “CS Frame Edit” menu. 2. Use [8] and [2] to select “DPOF Printing” and then press [SET]. 3. Use [8] and [2] to select “Frame all” and then press [SET]. 4. Use [8] and [2] to specify the number of copies. You can specify a value up to 99. Specify 00 if you do not want to print the image.
. Date Stamping You can use one of the following three methods to include the recording date in the printout of an image. Configuring camera settings Configure DPOF settings (page 120). You can turn date stamping on and off each time you print. You can configure settings so some images include the date stamp and some don’t. Configure the Camera’s Timestamp setting (page 147). • The camera’s Timestamp setting imprints the date into a snapshot when you shoot it, so the date is always included when you print.
Using the Camera with a Computer Things you can do using a computer... You can perform the operations described below while the camera is connected to a computer. Save images to a computer and view them there • Save images and view them manually (USB connection) (pages 126, 135). • Transfer images to a computer automatically over a wireless LAN for viewing (Eye-Fi) (page 140).
Using the Camera with a Windows Computer Install the required software in accordance with the version of Windows you are running and what you want to do. When you want to do this: Operating System Version Install this software: See page: Save images to a computer and view Vista / XP / 2000 them there manually Installation not required. 126 Play movies Vista / XP / 2000 Installation not required. • Windows Media Player, which is already installed on most computers, can be used for playback.
. Computer System Requirements for Bundled Software Computer system requirements are different for each of the applications. See the “Read me” file that comes with each application for details. Information about computer system requirements also can be found under “Computer System Requirements for Bundled Software” on page 166 of this manual. . Precautions for Windows Users • Except for Adobe Reader, the bundled software requires Administrator privileges to run.
4. Turn off the camera and then use the USB cable that comes with the camera to connect it to your computer. USB port USB cable Large connector USB/AV port Small connector Making sure that the 6 mark on the camera is aligned with the 4 mark of the USB cable connector, connect the cable to the camera. • The camera does not draw power over the USB cable. Check the battery level before connecting and make sure it is not too low.
6. Windows Vista users: Click “Start” and then “Computer”. Windows XP users: Click “Start” and then “My Computer”. Windows 2000 users: Doubleclick “My Computer”. 7. Double-click “Removable Disk”. • Your computer recognizes the memory card loaded in the camera (or built-in memory if there is no card) as a removable disk. 8. Right-click the “DCIM” folder. 9. On the shortcut menu that appears, click “Copy”. 10. Windows Vista users: Click “Start” and then “Documents”.
. To view images you copied to your computer 1. Double-click the copied “DCIM” folder to open it. 2. Double-click the folder that contains the images you want to view. 3. Double-click the image file you want to view. • For information about file names, see “Memory Folder Structure” on page 142. • An image that was rotated on the camera will be displayed on your computer screen in its original (unrotated) orientation.
Playing Movies Windows Media Player, which is already installed on most computers, can be used for movie playback. To play back a movie, first copy the movie to your computer and then double-click the movie file. . Minimum Computer System Requirements for HD Movie Playback The minimum system requirements described below are necessary to play back HD movies recorded with this camera on a computer. Operating System : Vista / XP / 2000 CPU : Pentium 4, 3.
Uploading Movie Files to YouTube Installing YouTube Uploader for CASIO from the CD-ROM that comes with your camera simplifies uploading of movie files you recorded with the “For YouTube” scene to YouTube. . What is YouTube? YouTube is a movie sharing site managed by YouTube, LLC where you can upload movies and view movies uploaded by others. . To install YouTube Uploader for CASIO 1. On the CD-ROM menu screen, select “YouTube Uploader for CASIO”. 2.
5. The left side of the display will have an area for inputting a title, category, and other information required for uploading to YouTube. Enter the required information. 6. The right side of the display shows a list of movie files in camera memory. Select the check box next to the movie file you want to upload. 7. When everything is ready, click the [Upload] button. This will upload the movie file(s) to YouTube. • After uploading is complete, click the [Exit] button to exit the application.
Transferring Images from Your Computer to Camera Memory If you want to transfer images from your computer to the camera, install Photo Transport on your computer from the CD-ROM that comes with the camera. . To install Photo Transport 1. On the CD-ROM menu screen, select “Photo Transport”. 2. After reading the information about installation conditions and system requirements for installation in the “Read me” file, install Photo Transport. . To transfer images to the camera 1.
. To transfer computer screen captures to the camera 1. Connect the camera to your computer (page 126). 2. On your computer, click the following: Start * All Programs * CASIO * Photo Transport. This starts up Photo Transport. 3. Display the screen whose screen capture you want to transfer. 4. Click the [Capture] button. 5. Draw a boundary around the area you want to capture. Move your mouse pointer to the upper left corner of the area you want to capture and then hold down the mouse button.
Using the Camera with a Macintosh Install the required software in accordance with what version of the Macintosh OS you are running and what you want to do. When you want to do this: Save images to your Macintosh and view them there manually Operating System Version OS 9 OS X Save images to your OS 9 Macintosh automatically/Manage OS X images Play movies OS 9 / OS X Install this software: See page: Installation not required. Use commercially available software.
4. Turn off the camera and then use the USB cable that comes with the camera to connect it to your Macintosh. USB port USB cable Large connector USB/AV port Small connector Making sure that the 6 mark on the camera is aligned with the 4 mark of the USB cable connector, connect the cable to the camera. • The camera does not draw power over the USB cable. Check the battery level before connecting and make sure it is not too low.
6. Double-click the camera’s drive icon. 7. Drag the “DCIM” folder to the folder to which you want to copy it. 8. After the copy operation is complete, drag the drive icon to Trash. 9. On the camera, press [ON/OFF] to turn off the camera. After making sure that the green back lamp is unlit, disconnect the camera from the computer. . To view copied images 1. Double-click the camera’s drive icon. 2. Double-click the “DCIM” folder to open it. 3.
Transferring Images Automatically and Managing Them on Your Macintosh If you are running Mac OS X, you can use the iPhoto application that comes bundled with the operating system to manage your images. If you are running Mac OS 9, you will need to use commercially available software. Playing a Movie You can use QuickTime, which comes bundled with your operating system, to play back movies on a Macintosh. To play back a movie, first copy it to your Macintosh and then double-click the movie file. .
Viewing User Documentation (PDF Files) You must have Adobe Reader or Adobe Acrobat Reader installed on your computer in order to view the contents of a PDF file. If you don’t, go to the Adobe Systems Incorporated website and install Acrobat Reader. 1. On the CD-ROM, open the “Manual” folder. 2. Open the “Digital Camera” folder and then open the folder for the language whose user’s guide you want to view. 3. Open the file named “camera_xx.pdf”. • “xx” is the language code (Example: camera_e.
Using an Eye-Fi Wireless SD Memory Card to Transfer Images (Eye-Fi) Shooting with an Eye-Fi wireless SD memory card loaded in the camera makes it possible to transfer image data automatically to a computer via wireless LAN. 1. Configure LAN access point, transfer destination and other settings for the Eye-Fi card in accordance with the instructions that come with the Eye-Fi card. 2. After configuring settings, load the Eye-Fi card into the camera and record.
Files and Folders The camera creates a file each time you shoot a snapshot, record a movie, or perform any other operation that stores data. Files are grouped by storing them in folders. Each file and folder has its own unique name. • For details about how folders are organized in memory, see “Memory Folder Structure” (page 142). Name and Maximum Number Allowed Example Each folder can contain up to 9999 files named CIMG0001 through CIMG9999. The extension on the file name depends on the file type.
Memory Card Data The camera stores images you shoot in accordance with the Design Rule for Camera File System (DCF). . About DCF DCF is a standard that makes it possible to view and print images recorded on one manufacturer’s camera on DCF-compliant devices produced by other manufacturers. You can transfer DCF-compliant images recorded with another camera to this camera and view them on this camera’s monitor screen. . Memory Folder Structure 100CASIO *1 CIMG0001.JPG CIMG0002.
. Supported Image Files • Image files shot with this camera • DCF-compliant image files This camera may not be able to display an image, even if it is DCF-compliant. When displaying an image recorded on another camera, it may take a long time for the image to appear on this camera’s monitor screen. . Built-in Memory and Memory Card Data Handling Precautions • Whenever copying memory contents to your computer, you should copy the DCIM folder and all of its contents.
Other Settings (Set Up) This section explains menu items that you can use to configure settings and perform other operations in both the REC mode and PLAY mode. For information about menu operations, see page 77. Adjusting Monitor Screen Brightness (Screen) Procedure [MENU] * Set Up Tab * Screen With this setting, the camera detects available light levels and Auto 2/ automatically adjusts the brightness of the monitor screen accordingly.
Configuring Camera Sound Settings (Sounds) Procedure [MENU] * Set Up Tab * Sounds Startup Specifies the startup sound Sound 1 - 5: Built-in sounds (1 through 5) Off: Sound off Half Shutter Shutter Operation = Operation Specifies the sound volume. This setting is also used as the audio level during video output (page 151). = Play Specifies the volume of movie audio output. This volume setting is not used during video output (from the USB/AV port) (page 150). • Setting a volume level of 0 mutes output.
Configuring World Time Settings (World Time) Procedure [MENU] * Set Up Tab * World Time You can use the World Time screen to view the current time in a zone that is different from your Home City when you go on a trip, etc. World Time displays the current time in 162 cities in 32 time zones around the globe. 1. Use [8] and [2] to select “World” and then press [6]. • To change the geographic area and city for the time where you normally use the camera, select “Home”. 2.
Time Stamping Snapshots (Timestamp) Procedure [MENU] * Set Up Tab * Timestamp You can configure the camera to stamp the recording date only, or date and time in the lower right corner of each snapshot. • Once date and time information is stamped into a snapshot, it cannot be edited or deleted. Example: December 30, 2009, 1:25 p.m.
Specifying the Date Style (Date Style) Procedure [MENU] * Set Up Tab * Date Style You can select from among three different styles for the date. Example: December 30, 2009 YY/MM/DD 09/12/30 DD/MM/YY 30/12/09 MM/DD/YY 12/30/09 • This setting also affects the control panel date format as shown below (page 31). YY/MM/DD or MM/DD/YY: MM/DD DD/MM/YY: DD/MM Specifying the Display Language (Language) Procedure [MENU] * Set Up Tab * Language . Specify the display language you want.
Configuring Sleep State Settings (Sleep) Procedure [MENU] * Set Up Tab * Sleep This feature turns off the monitor screen whenever no camera operation is performed for a preset amount of time. Press any button to turn the monitor screen back on. Trigger Time Settings: 30 sec, 1 min, 2 min, Off (Sleep is disabled while “Off” is selected.) • Sleep is disabled under any of the following conditions.
Configuring [r] and [p] Settings (REC/PLAY) Procedure [MENU] * Set Up Tab * REC/PLAY Power On Camera turns on whenever [r] (REC) or [p] (PLAY) is pressed. Power On/Off Camera turns on or off whenever [r] (REC) or [p] (PLAY) is pressed. Disable Camera does not turn on or off when [r] (REC) or [p] (PLAY) is pressed. • With “Power On/Off”, the camera turns off when you press [r] (REC) in the REC mode or [p] (PLAY) in the PLAY mode.
Selecting the Screen Aspect Ratio and Video Output System (Video Out) Procedure [MENU] * Set Up Tab * Video Out You can use the procedure in this section to select either NTSC or PAL as the video output system. You can also specify an aspect ratio of 4:3 or 16:9. NTSC Video system used in Japan, the U.S.
Formatting Built-in Memory or a Memory Card (Format) Procedure [MENU] * Set Up Tab * Format If a memory card is loaded in the camera, this operation will format the memory card. It will format built-in memory if no memory card is loaded. • The format operation will delete all contents on the memory card or in built-in memory. It cannot be undone. Make sure you do not need any data currently on the card or in built-in memory before you format it. • Formatting built-in memory will delete the following data.
Configuring Monitor Screen Settings Turning Display Information On and Off (Info) Each press of [8] (DISP) will cycle through display settings that display or hide onscreen information and the control panel. You can configure separate settings for the REC mode and PLAY mode. Information on, control panel on Displays setting information and the control panel.
How to Use the Histogram A histogram is a graph that represents the lightness of an image in terms of the number of pixels. The vertical axis indicates the number of pixels, while the horizontal axis indicates lightness. If the histogram appears too lopsided for some reason, you can use EV shift to move it left or right in order to achieve better balance. Optimum exposure can be achieved by EV shifting so the graph is as close to the center as possible.
Appendix Precautions during Use . Avoid Use While In Motion • Never use the camera to record or play back images while operating an automobile or other vehicle, or while walking. Looking at the monitor while in motion creates the risk of serious accident. . Flash • Never use the flash unit in areas where flammable or explosive gas may be present. Such conditions create the risk of fire and explosion. • Never fire the flash in the direction of a person operating a motor vehicle.
. Smoke, abnormal odor, overheating, and other abnormalities • Continued use of the camera while it is emitting smoke or strange odor, or while it is overheating creates the risk of fire and electric shock. Immediately perform the following steps whenever any of the above symptoms are present. 1. Turn off the camera. 2. Remove the battery from the camera, taking care to protect yourself against burn injury. 3. Contact your dealer or nearest CASIO authorized service center. .
. Locations To Be Avoided • Never leave the camera in any of the following types of locations. Doing so creates the risk of fire and electric shock. – Areas subject to large amounts of humidity or dust – Food preparation areas or other locations where oil smoke is present – Near heaters, on a heated carpet, in areas exposed to direct sunlight, in a closed vehicle parked in the sun, or other areas subject to very high temperatures • Never place the camera on an unstable surface, on a high shelf, etc.
• Do not use or leave the battery under direct sunlight, in an automobile parked in the sun, or in any other area subject to high temperatures. Doing so can damage the battery, and cause deterioration of its performance and loss of service life. • If battery charging does not end normally within the specified charging time, stop charging anyway and contact your local CASIO authorized service center. Continued charging creates the risk of battery overheating, fire, and explosion.
. Data Error Precautions Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory.
. Caring for your camera • Never touch the lens or flash window with your fingers. Finger smudges, dirt, and other foreign matter on the lens or flash window can interfere with proper operation of the camera. Use a blower or other means to keep the lens and flash window free of dirt and dust, and wipe gently with a soft, dry cloth. • To clean the camera, wipe it with a soft, dry cloth. . Old Rechargeable Battery Handling Precautions • Insulate the positive and negative terminals with tape, etc.
. Other Precautions The camera becomes slightly warm during use. This is normal and does not indicate malfunction. . Copyrights Except for your own personal enjoyment, unauthorized use of use of snapshots or movies of images whose rights belong to others, without the permission of the right holder, is forbidden by copyright laws. In some cases, shooting of public performances, shows, exhibitions, etc. may be restricted entirely, even if it is for your own personal enjoyment.
Any and all unauthorized commercial copying, distribution, and copying of the bundled software over a network are prohibited. This product contains PrKERNELv4 Real-time OS of eSOL Co., Ltd. Copyright © 2007 eSOL Co., Ltd. PrKERNELv4 is a registered trademark of eSOL Co., Ltd. in Japan. This product’s YouTube upload functionality is included under license from YouTube, LLC. The presence of YouTube upload functionality in this product is not an endorsement or recommendation of the product by YouTube, LLC.
To replace the battery 1. Open the battery cover and remove the current battery. Stopper With the monitor screen side of the camera facing upwards, slide the stopper in the direction indicated by the arrow in the illustration. After the battery pops out, pull it the rest of the way out of the camera. 2. Load a new battery. Battery Precautions . Precautions during Use • Operation provided by a battery under cold conditions is always less than operation under normal temperatures.
Using the Camera in another Country . Precautions during Use • The bundled charger is designed for operation with any power supply in the range of 100V to 240V AC, 50/60Hz. Note, however, that the shape of the power cord plug depends on each country or geographic area. Before taking the camera and charger along on a trip, check with travel agent about the power supply requirements in your destination(s). • Do not connect the charger to a power supply through a voltage converter or similar device.
. Using a Memory Card • SD memory cards and SDHC memory cards have a Write enabled write protect switch. Use the switch when you need to guard against accidentally deleting data. Note, however, if you write protect an SD memory card you Write disabled must then turn write protection off whenever you want to record to it, format it, or delete any of its images. • If a memory card starts to behave abnormally during image playback, you can restore normal operation by reformatting it (page 152).
Computer System Requirements for Bundled Software Computer system requirements are different for each of the applications. Be sure to check the requirements for the particular application you are trying to use. Note that the values provided here are minimum requirements for running each application. Actual requirements are greater, depending on the number of images and the sizes of the images being handled.
Reset Initial Default Settings The tables in this section show the initial default settings that are configured for menu items (displayed when you press [MENU]) after you reset the camera (page 152). Menu items depend on whether the camera is in the REC mode or PLAY mode. • A dash (–) indicates an item whose setting is not reset or an item for which there is no reset setting. .
“Set Up” Tab Screen Auto 2 Adjust – Eye-Fi On Date Style – Language – Sleep 1 min Sounds Startup: Sound 1 / Half Shutter: Sound 1 / Shutter: Sound 1 / Operation: Sound 1 / = Operation: ...//// / = Play: ...
When things don’t go right... Troubleshooting Problem Possible Cause and Recommended Action Power Supply Power does not turn on. 1)The battery may not be loaded correctly (page 17). 2)The battery may be dead. Charge the battery (page 16). If the battery goes dead soon after being charged, it means the battery has reached the end of its life and needs to be replaced. Purchase a separately available CASIO NP-60 rechargeable lithium ion battery. The camera suddenly powers down.
Problem Possible Cause and Recommended Action The subject is out of focus in the recorded image. The image may not be focused properly. When composing the image, make sure the subject is located inside the focus frame. The flash does not fire. 1)If ? (Flash Off) is selected as the flash mode, change to another mode (page 42). 2)If the battery is low, charge it (page 16).
Problem Possible Cause and Recommended Action Though available lighting is bright, the faces of people in the image are dark. Not enough light is reaching the subjects. Change the flash mode setting to < (Flash On) for daylight synchro flash (page 42), or adjust EV shift to the + side (page 37). Night shots come out bad. Use the following BEST SHOT scenes (page 63) when shooting at night.
Problem Possible Cause and Recommended Action Playback The color of the playback image is different from what appears on the monitor screen when shooting. Sunlight or light from another source may be shining directly into the lens when you are shooting. Position the camera so sunlight does not shine directly into the lens. Images are not displayed. This camera cannot display non-DCF images recorded onto a memory card using another digital camera.
Problem Possible Cause and Recommended Action Language selection 1)You did not configure initial settings after purchasing the screen appears camera or the battery may have been left with a dead battery. when the camera is Configure the correct settings (pages 19, 148). turned on. 2)There may be a problem with the camera’s memory data. If this is the case, perform the reset operation to initialize the camera’s setup (page 152). After that, configure each setting.
Display Messages ALERT The camera’s protection function may have activated because camera temperature is too high. Turn off the camera and wait until it cools down before trying to use it again. Battery is low. Battery power is low. Camera not in standby. Re-frame the image. The camera could not go into auto record standby for some reason during a Move Out CS or Move In CS operation. Compose the image again with the boundary aligned correctly (page 72). Cannot find the file.
Load paper! The printer ran out of paper while printing. Memory Full Memory is full with images you recorded and/or files saved by editing operations. When shooting with Prerecord CS, this message indicates that there is not enough memory capacity to record all of the pre-recorded images. Delete files you no longer need (page 29). Printing Error An error occurred while printing. • The printer is turned off. • The printer generated an error, etc.
Number of Snapshots/Movie Recording Time Snapshot Image Size (Pixels) 9M (3456x2592) 3:2 (3456x2304) 16:9 (3456x1944) 6M (2816x2112) 4M (2304x1728) 2M (1600x1200) VGA (640x480) Image Quality Approximate Image File Size Built-in Memory Snapshot Recording Capacity SD Memory Card (1GB) Snapshot Recording Capacity Fine 5.66 MB 5 Normal 3.0 MB 10 170 322 Economy 2.02 MB 15 478 Fine 4.94 MB 6 195 Normal 2.64 MB 11 366 Economy 1.78 MB 17 543 Fine 4.04 MB 8 239 443 Normal 2.
Movies Movie Mode HD/ STD Approximate Data Rate (Frame Rate) Built-in Memory Movie Recording Capacity SD Memory Card (1GB) Movie Recording Capacity File Size of 1-minute Movie HD 1280x720 (Monaural) 30 Megabits/second (30 frames/second) 8 seconds 4 minutes 22 seconds 225 MB STD 640x480 (Monaural) 10 Megabits/second (30 frames/second) 26 seconds 12 minutes 57 seconds 75 MB 50 Megabits/second (210 frames/second) 5 seconds 2 minutes 38 seconds 375 MB 50 Megabits/second (420 frames/second)
Movie Mode Approximate Data Rate (Frame Rate) Built-in Memory Movie Recording Capacity SD Memory Card (Maximum recording time per recording) YouTube (HS210 fps) 480x360 (No audio) 50 Megabits/second (210 frames/second) 5 seconds 1 minute 25 seconds YouTube (HS420 fps) 224x168 (No audio) 50 Megabits/second (420 frames/second) 5 seconds 42 seconds 25 Megabits/second (1000 frames/second) 10 seconds 18 seconds 7.
Specifications File Format Snapshots: JPEG (Exif Version 2.2); DCF 1.0 standard; DPOF compliant Movies: Motion JPEG AVI, IMA-ADPCM audio (monaural) Recording Media Built-in Memory (Image Storage Area: 31.
Exposure Compensation –2.0 EV to +2.0 EV (in 1/3EV steps) Shutter CMOS electronic shutter, mechanical shutter Shutter Speed Snapshot (Auto): 1 to 1/1250 second (1/40000 second for High Speed CS only) Snapshot (Night Scene): 4 to 1/1250 second * May differ due to the camera setup. Aperture Value F3.9 (W) to F7.
Input/Output Terminals USB/AV port, Hi-Speed USB compatible Microphone Monaural Speaker Monaural Power Requirements Rechargeable lithium ion battery (NP-60) x1 181 Appendix
Approximate Battery Life All of the values provided below represent the approximate amount of time under normal temperature (23°C (73°F)) before the camera turns off. These values are not guaranteed. Low temperatures shorten battery life.
. Rechargeable lithium ion battery (NP-60) Rated Voltage 3.7 V Rated Capacitance 720 mAh Operating Temperature 0 to 40°C (32 to 104°F) Dimensions 37.9 (W) x 42.3 (H) x 5.0 (D) mm (1.49" (W) x 1.67" (H) x 0.20" (D)) Weight Approximately 18 g (0.63 oz) . Charger unit (BC-60L) Input Power 100 to 240 V AC, 80 mA, 50/60 Hz Output Power 4.
CASIO COMPUTER CO.,LTD.
