Operating Guide
36
4.6 adjuSt hItch heIght (If equIpped)
The height of the hitch on the trailer must be adjusted
so that the trailer, when loaded to rated capacity, is
level while connected to the tow vehicle. A level trailer
allows equal weight distribution on the axles.
Your dealer or a trailer service center can perform this
adjustment or you can use the following steps to adjust
the hitch height yourself.
If the trailer is not equipped with an adjustable hitch,
an offset ball mount may be available from your hitch
manufacturer.
^ WARNING
Improper hitch height adjustment can
result in overloaded tires, blowout and
loss of control, leading to death or serious
injury.
Adjust the hitch height so that the loaded
trailer is level.
1. Connect trailer to tow vehicle and load the trailer to
rated capacity. See Loading And Unloading.
2. Park the tow vehicle and trailer on a rm level
surface.
3. Stand away from the trailer and visually verify if the
trailer is level front-to-rear. If the front of the trailer
is higher than the rear, the hitch must be raised.
If the front of the trailer is lower than the rear, the
hitch must be lowered.
4. Uncouple trailer from tow vehicle. See Uncoupling
And Uncoupling.
5. Remove the lock nuts and bolts on hitch. Discard
lock nuts. Inspect bolts for damage and replace if
necessary. Contact your dealer for the correct size
and grade of bolts.
^ WARNING
Used lock nuts are prone to loosen,
resulting in the hitch separating from the
trailer, which can lead to death or serious
injury.
NEVER re-use a lock nut.
Use new lock nuts each time the hitch
height is adjusted.
Contact your dealer for the proper grade
and size of lock nut.
6. Raise or lower the hitch as necessary.
7. Install bolts and new lock nuts.
8. Tighten lock nuts to torque specied by your
dealer.
9. Couple the trailer to the tow vehicle and verify that
the trailer is level front to rear. Adjust if necessary.
10. Unload trailer. See Loading And Unloading.
Coupling To Tow Vehicle
