QUICK REFERENCE

Heat/Cool Units

MODEL

NUMBER

COOLING

(Btuh)

EER

ELECTRIC

HEAT (Btuh)

EVAP. FAN

CFM

(HI

SPEED)

APPROX.

WGT

(SHIP)

1-PH, 60-Hz

VOLTS

CURRENT (AMPS) POWER (WATTS)

BRANCH

CIRCUIT

FUSE

(AMPS)

Cooling

Electric

Heat

Cooling

Electric

Heat

52SEE207---3 7,100/ 7,000 11.0/11.1 7,800/ 6,400 280 128 230/208 2.8/3.0 10.6/ 9.6 645/ 628 2440/2040 15

52SEE307---3 7,100/ 7,000 11.0/11.1 11,600/ 9,500 280 128 230/208 2.8/3.0 15.4/14.2 645/ 628 3540/2990 20

52SEE209---3 9,100/ 9,100 9.3/ 9.3 7,800/ 6,400 350 120 230/208 4.4/4.6 10.8/ 9.9 979/ 979 2440/2025 15

52SEE309---3 9,100/ 9,100 9.3/ 9.3 11,600/ 9,500 350 120 230/208 4.4/4.6 15.6/14.5 979/ 979 3540/2975 20

52SEC212---3 11,800/11,600 9.0/ 9.0 7,800/ 6,400 380 129 230/208 5.9/6.3 11.0/ 9.9 1310/1288 2500/2075 15

52SEC312---3 11,800/11,600 9.0/ 9.0 11,600/ 9,500 380 129 230/208 5.9/6.3 15.8/14.5 1310/1288 3600/3025 20

52SEC512---3 11,800/11,600 9.0/ 9.0 16,900/13,600 380 129 230/208 5.9/6.3 22.7/20.0 1310/1288 5200/4175 30

52SEC214---3 13,500/13,200 8.8/ 8.8 7,800/ 6,400 300 129 230/208 6.8/7.3 10.9/ 9.8 1530/1500 2510/2070 15

52SEC314---3 13,500/13,200 8.8/ 8.8 11,600/ 9,500 300 129 230/208 6.8/7.3 15.7/14.4 1530/1500 3610/3020 20

52SEC514---3 13,500/13,200 8.8/ 8.8 16,900/13,600 300 129 230/208 6.8/7.3 22.6/19.9 1530/1500 5210/4170 30

52SED207---4 7,100 11.0 7,800 280 125 265 2.7 9.3 645 2435 15

52SED307---4 7,100 11.0 11,600 280 125 265 2.7 13.4 645 3535 20

52SEE209---4 9,100 9.5 7,800 350 120 265 3.8 9.4 958 2435 15

52SEE309---4 9,100 9.5 11,600 350 120 265 3.8 13.5 958 3535 20

52SEC212---4 12,000 9.2 7,800 380 129 265 5.2 9.5 1304 2508 15

52SEC312---4 12,000 9.2 11,600 380 129 265 5.2 13.6 1304 3608 20

52SEC512---4 12,000 9.2 17,000 380 129 265 5.2 19.7 1304 5208 25

52SEC214---4 13,700 9.0 7,800 350 130 265 5.9 9.5 1522 2505 15

52SEC314---4 13,700 9.0 11,600 350 130 265 5.9 13.6 1522 3605 20

52SEC514---4 13,700 9.0 17,000 350 130 265 5.9 19.7 1522 5205 25

Heat Pumps

MODEL

NUMBER

COOLING

(Btuh)

EER COP

REVERSE

CYCLE

HEAT

(Btuh)

EVAP.

FAN

CFM

(HI

SPEED)

APPROX.

WGT

(SHIP)

1-PH,60-Hz

VOLTS

CURRENT (AMPS) POWER (WATTS)

BRANCH

CIRCUIT

FUSE

(AMPS)

Cooling

Electric

Heat

Cooling

Electric

Heat

52SQD207---3 7,100/ 6,900 10.5/10.5 3.1/3.1 6,100/ 6,000 280 125 230/208 2.9/3.1 10.6/ 9.6 675/ 655 2440/2040 15

52SQD307---3 7,100/ 6,900 10.5/10.5 3.1/3.1 6,100/ 6,000 280 125 230/208 2.9/3.1 15.4/14.2 675/ 655 3540/2990 20

52SQD209---3 8,800/ 8,600 9.5/ 9.5 2.8/2.8 7,900/ 7,800 340 128 230/208 4.4/4.7 10.9/ 9.8 925/ 905 2510/2070 15

52SQD309---3 8,800/ 8,600 9.5/ 9.5 2.8/2.8 7,900/ 7,800 340 128 230/208 4.4/4.7 15.7/14.4 925/ 905 3610/3020 20

52SQC212---3 12,000/11,800 9.0/ 9.0 2.8/2.8 10,700/10,600 380 129 230/208 5.8/6.2 11.0/ 9.9 1275/1255 2500/2075 15

52SQC312---3 12,000/11,800 9.0/ 9.0 2.8/2.8 10,700/10,600 380 129 230/208 5.8/6.2 15.8/14.5 1275/1255 3600/3025 20

52SQC512---3 12,000/11,800 9.0/ 9.0 2.8/2.8 10,700/10,600 380 129 230/208 5.8/6.2 22.7/20.0 1275/1255 5200/4175 30

52SQC214---3 13,500/13,200 8.8/ 8.8 2.6/2.6 11,000/11,000 300 130 230/208 6.9/7.4 10.9/ 9.8 1530/1500 2510/2070 15

52SQC314---3 13,500/13,200 8.8/ 8.8 2.6/2.6 11,000/11,000 300 130 230/208 6.9/7.4 15.7/14.4 1530/1500 3610/3020 20

52SQC514---3 13,500/13,200 8.8/ 8.8 2.6/2.6 11,000/11,000 300 130 230/208 6.9/7.4 22.6/19.9 1530/1500 5210/4170 30

52SQD207---4 7,100 10.5 2.9 6,000 280 125 265 2.9 9.3 675 2435 15

52SQD307---4 7,100 10.5 2.9 6,000 280 125 265 2.9 13.4 675 3535 20

52SQD209---4 8,800 9.5 2.8 7,900 350 128 265 3.9 9.4 938 2435 15

52SQD309---4 8,800 9.5 2.8 7,900 350 128 265 3.9 13.5 938 3535 20

52SQC212---4 12,000 9.0 2.8 11,000 350 129 265 5.2 9.5 1333 2508 15

52SQC312---4 12,000 9.0 2.8 11,000 350 129 265 5.2 13.6 1333 3608 20

52SQC512---4 12,000 9.0 2.8 11,000 350 129 265 5.2 19.7 1333 5208 25

52SQC214---4 13,500 8.8 2.7 11,000 350 130 265 5.9 9.5 1535 2505 15

52SQC314---4 13,500 8.8 2.7 11,000 350 130 265 5.9 13.6 1535 3605 20

52SQC514---4 13,500 8.8 2.7 11,000 350 130 265 5.9 19.7 1535 5205 25

RECEPTACLE

15 Amps

250 Volts

20 Amps

250 Volts

30 Amps

250 Volts

15 Amps

265 Volts

20 Amps

265 Volts

25/30 Amps

265 Volts

HEATER 2.3 kW 3.4 kW 5.0 kW 2.3 kW 3.4 kW 5.0 kW

LEGEND

COP — Coefficient of Performance

EER — Energy Efficiency Ratio

Wgt — Weight
