Setup of DS0 Management Channel
Configuration of Access Navigator
Note: The Ethernet cannot be connected to the Remote Axxius during the
setup of the DS0.
The following setup, creates a path from the Axxius Router to the remote Axxius.
Note: the following commands are assuming that the Access Navigator is set
to factory defaults.
Command Description
set ds1 1-32 down Sets 1-32 Out-of-Service
set ethernet ip address
192.168.201.100
255.255.255.0
Sets the Ethernet IP address of the Navigator and it’s
subnet mask
set ip gateway
192.168.201.101
Sets the gateway (router address)
set ds1 32 type groom Sets DS1 32 to groom
set ds0 32:1-24 type data Sets DS0 32 1-24 to data signaling type
set ds1 1 remote device
mgmt caip 192.168.202.1
Sets DS1 1 as the Management Channel with the Router
(address listed)
set ds0 1:24 type data Sets DS0 1-24 to data signaling type
connect 1:24 32:1 Connects DS1 1:DS0 24 to DS1 32, DS0 1
set ds1 32 up Sets DS1 32 In Service
set ds1 1 up Sets DS1 1 In Service
set snmp nms1
xxx.xxx.xxx.xxx
Sends alarms to server. xxx.xxx.xxx.xxx is the IP
Address of the server.
show ds1 1 Displays DS1 1 information
show ip Displays IP Address information
show connect 1 Displays connections on DS1 1
status remote 1 Displays the status of the Management Channel
