Axxius 800 User Manual

Axxius 800 - Release 2.2 4-17
Configuration
Setup of DS0 Management Channel
Set IP Configuration of PC
1. Set IP Address to 192.168.201.102
2. Set Gateway to 192.168.201.101 (Router LAN Address)
Configuring the Axxius Router
NOTE: The Remote Axxius WAN address MUST have a different subnet
than the Axxius Controller Ethernet address.
WAN Connections
The following WAN connections are made from a default condition with one (1)
TSR card installed set with factory defaults.
NOTE: An Axxius TSR is capable of managing 24 virtual WAN
connections through one of the ports of the Controller card. If support of
more than 24 Axxius units is required a Quad T1 and TSR card(s) can be
added; this however, can only be done on the collocated TSR, not on a
remote Axxius.
1. From the CLI execute the following command to connect one DS0 to each one
of the 24 WANs.
Command Description
set local off Sets the Axxius to be configured through CLI
set a:1 down Sets port 1 of the Controller as Out-of-Service
disconnect a Disconnects all connections to slot a (controller)
set a:1:1-24 type data Sets all DS0s on the DS1-1 to data signaling type
connect a:1:1 1:1:1 Connects first DS0 of port 1 of the Controller to
port 1, WAN 1 of the Router in slot 1.
connect a:1:2 1:1:2 Connects second DS0 of port 1 of the Controller to port
1, WAN 2 of the Router in slot 1.
connect a:1:3 1:1:3 Up to 24 WAN connections (a:1:24 1:1:24)
