Axxius 800 - Release 2.2 3-5
Electrical Installation and Cabling
Chassis Connections
Front of the Axxius 800 - Interface Card
l 10Base-T Ethernet (RJ-45)
l RS-232 Craft Port
l DS3-1 and 2 Transmit and Receive connectors (SMB)
l DS1 (1-4) connectors (RJ-48)
For information on this card and all connectors see Control Panel Interfaces on page 1-11.
CAUTION! THE AXXIUS 800 CONTAINS CIRCUIT CARDS AND COMPONENTS THAT
ARE SUBJECT TO DAMAGE BY ELECTROSTATIC DISCHARGE (ESD). ALWAYS
FOLLOW THE ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS, ON PAGE XXII.
DS3 (SMB)
Connectors (4)
RS-232
10Base-T
Ethernet
DS1 (RJ-48)
Connectors (4)
