16-8 Axxius 800 - Release 2.2

V.35/.54 Card

Connector Pinouts

LEDs

Each V.35 port has an LED, with definitions as shown in the table below.

Sub-miniature

DB-26

Signal Winchester

34-pin (female)

Paired

Signals

15  Receive Clock A → V



17  Receive Clock B → X



22 ← Local Loopback  J



25 ← Remote Loopback  BB



9, 13, 18 Open Pins/No Contact L, N, NN

19, 21, 26 Open Pins/No Contact

State Description

Off No T1 Assignment

Green Normal (CD/RTS) Active

Red CD inactive (T1-side failure)

Yellow RTS inactive (equipment-side failure)

Flashing Yellow Loopback toward T1 or equipment loop test

Flashing Green Loopback toward equipment or network loop test
