1-16 Axxius 800 - Release 2.2

Base Platform

Control Panel LEDs

Ethernet LEDs

When Status LED is on or flashing:

LED State Description

STATUS Off Link Down

Green Link Up

Flashing Green Traffic on Link

LED State Description

10/100 Off Link is 10 Mb

Green Link is 100 Mb
