Axxius 800 - Release 2.2 16-7
V.35/.54 Card
Connector Pinouts
Connector Pinouts
V.35 DCE (DB-26)
The V.35 DCE data port connection is made at the sub-miniature DB-26 connector on
the Axxius 800 using the 10-foot, 25-foot, or 50 foot Carrier Access DTE V.35 cable
equipped with a sub-miniature DB-26 connector and a 34-pin Winchester connector.
This cable is used to connect the Axxius 800 V.35 DCE data ports to synchronous V.35
DTE data sources up to 1.536 Mbps, all rates (1-24) Nx56 or Nx64 channel-rate
progression.
The Carrier Access Corporation V.35 data cables are built according to the pin
assignments listed below:
Sub-miniature
DB-26
Signal Winchester 34-pin
(female)
Paired
Signals
1 (+ Shield) ← Protective Ground → A
7 ← Signal Ground → B
2 ← Transmit Data A P
14 ← Transmit Data B S
3 Receive Data A → R
16 Receive Data B → T
4 ← RTS C
20 ← DTR H
5 CTS → D
6 DSR → E
12 Test Mode → K
8 CD (RLSD) → F
11 ← External Clock A U
24 ← External Clock B W
10 Xmit Clock A → Y
23 Xmit Clock B → AA
