Axxius 800 - Release 2.2 1-15
Base Platform
Control Panel LEDs
Control Panel LEDs
Alarm LEDs
LED State Description
CRITICAL Off No critical alarms present
Red Critical alarms present
MAJOR Off No major alarms present
Red Major alarm present
MINOR Off No minor alarms present
Red Minor alarms present
ACO Off Normal mode. No alarms are being suppressed.
Red Alarm cutoff active. One or more active alarms
suppressed.
