Axxius 800 - Release 2.2 13-11
Quad DS1 ADPCM Card
Connector Pinouts
Connector Pinouts
RJ-48 Connector
There are four RJ-48 (female) connectors on the front of the Quad DS1 ADPCM Card.
The pinouts are as follows:
Pin Name Description
1 Receive Ring Receive from DS1 network
2 Receive Tip Receive from DS1 network
3 n/c Not connected
4 Transmit Ring To DS1 network
5 Transmit Tip To DS1 network
6 - 7 n/c Not connected
8 Chassis Ground
