Axxius 800 - Release 2.2 11-7

Single Channel POTS Cards

LEDs

The POTs channel LED (left) status is described in the table below.

The second LED (right) is a status LED for the MODEM.

State Loop Start Meaning

Off Calling Party Disconnect

Green Idle

Red N/A

Yellow Call in progress

Flashing green Ringing

State Description

Off Calling Party Disconnect

Green Ringing

Yellow Carrier Detect
