9-8 Axxius 800 - Release 2.2

ISDN BRI Card

Connector Pinouts

Wire-Wrap Pinout 2 Wire Services

The following pinout applies to the wire-wrap pinout for the slot of the ISDN BRI card.

Wire-Wrap Pins Description

T1 Channel 1 Transmit Tip

R1 Channel 1 Transmit Ring

T2 Channel 2 Transmit Tip

R2 Channel 2 Transmit Ring

T3 Channel 3 Transmit Tip

R3 Channel 3 Transmit Ring

T4 Channel 4 Transmit Tip

R4 Channel 4 Transmit Ring

T5 Channel 5 Transmit Tip

R5 Channel 5 Transmit Ring

T6 Channel 6 Transmit Tip

R6 Channel 6 Transmit Ring

T7 Channel 7 Transmit Tip

R7 Channel 7 Transmit Ring

T8 Channel 8 Transmit Tip

R8 Channel 8 Transmit Ring
