Axxius 800 - Release 2.2 7-7
DS3 Controller Card
Controller Active and Standby
Controller Active and Standby
The Axxius 800 can function fully with a single Controller card, however Controller
redundancy is available with two like Controllers (DS1 or DS3) installed. When two
Controllers are installed in a system, one is always Active and the other is Standby. The
Standby can have 2 conditions:
l Hot Standby - meaning that the card is ready to take over for the active and the
switch will not affect service
l Cold Standby - meaning that the card is ready to go active (healthy) but for some
reason (code of the 2 controllers is not the same) it will need to reconfigure the
box when it goes active, which will be service affecting.
There are two ways to identify the status of the Controllers.
1. CLI Command status equipment
> status equipment
CardType Status SW Vers CLEI
SLOT P1 +24 V Healthy SIPUMR0DAA
SLOT P2 Card not installed
SLOT A1 T3x4 Active 1.1.0 SIIX4W0DAA
SLOT A2 T3x4 Hot Standby 1.1.0 SIIX4W0DAA
SLOT B1 Card not installed
SLOT B2 Card not installed
SLOT 1 TSRx4 Present 1.00 NOT AVAIL
SLOT 2 T1x4 Present 1.73 SIIXFWBDAA
SLOT 3 V35x2 Present 2.01 SIC3HK0CAA
SLOT 4 V35x2 Present 2.01 SIC3HK0CAA
SLOT 5 BRIx8 Present 1.11 SIIXUX0DAA
SLOT 6 OCUDPx1 Present 1.01 SIIXA4DDAA
SLOT 7 FXOx8 Present 1.12 SIIXPV0DAA
SLOT 8 FXSPSMx1 Present 0.01
SLOT 9 Card not installed
2. Visually looking at the Controller cards.
Active - STAT LED will be solid green.
Hot Standby - STAT LED will be solid yellow
Cold Standby - STAT LED will be flashing yellow
