5-242 Axxius 800 - Release 2.2

CLI Commands

status

status (ocudp)

Use the status (ocudp) command to displaystatus for selftest and loopbacks.

Syntax: status {ocudp-addr}

Example: status 2:1

SLOT 2:

Status for OCUDP Port 1:

Selftest:

Results as of 23:25:48 01/07/2001

Datapath: PASS

FPGA: PASS

OCU: PASS

OCU Manual Loopback: NONE

CSU Manual Loopback: NONE

OCU NonLatching Loopback: NONE

DSU NonLatching Loopback: NONE

CSU NonLatching Loopback: NONE

OCU Latching Loopback: NONE

DSU Latching Loopback: NONE

CSU Latching Loopback: NONE

{ocudp-addr}

The {slot:port} address of the OCU-DP card to display.

slot Slot number (1-8) where the OCU-DP is located

port Port number or range.
