Axxius 800 - Release 2.2 5-235

CLI Commands

status

status (ds3)

Use the status (ds3) command to display the current status of the specified DS3.

Syntax: status {ds3-addr}

Example: status a:1

> status a:1

SLOT A:

Status for DS3 1 DS1 1:

Status for DS3 1:

Receive: Loss of Framing

Transmit: Traffic

Loopback: OFF

{ds3-addr}

In the form of {slot port}:

slot A, with a DS3 controller card installed.

port Port number or range. Range of ports is 1-2
