5-228 Axxius 800 - Release 2.2

CLI Commands

status

status (bri)

Use the status (bri) command to display the status information for the ISDN BRI card.

Syntax: status {bri-addr}

Example: status 3:1

The example displays status of port 1 (BRI) on slot 3.

> status 3:1

SLOT 3:

Status for BRI Port 1:

Loopback: NONE

Corrupt CRC: NONE

{bri-addr}

The BRI address, in the form {slot:port}.

slot The slot number (1-8) that contains the BRI card

port Port number, range or all
