Axxius 800 - Release 2.2 5-227
CLI Commands
status
status (adpcm) performance history
Use the status (adpcm) performance history command to display performance statistics for
the current 15 minute interval and all previous 15 minute intervals (up to a total of 96) for the
ADPCM card.
Syntax: status {adpcm-addr} performance history
Example: status 6:1 performance history
> status 6:1 performance history
SLOT 6:
Performance Statistics for DS1 1:
UA S SES ES SEFS LES CSS BES DM LC V P CV
curr. interval: 317 0 0 0 0 0 0 0 0 0
prev. intvl 1: 900 0 0 0 0 0 0 0 0 0
prev. intvl 2: 900 0 0 0 0 0 0 0 0 0
prev. intvl 3: 900 0 0 0 0 0 0 0 0 0
prev. intvl 4: 900 0 0 0 0 0 0 0 0 0
.
.
.
prev. intvl 93: 900 0 0 0 0 0 0 0 0 0
prev. intvl 94: 900 0 0 0 0 0 0 0 0 0
prev. intvl 95: 900 0 0 0 0 0 0 0 0 0
prev. intvl 96: 900 0 0 0 0 0 0 0 0 0
totals: 21181 0 0 0 0 0 0 0 0 0
elapsed time in current 15 min. interval: 5:17
valid 15 min. intervals in data: 96
{adpcm-addr}
The ADPCM address is in the form {slot:port}.
slot Slot number (1-8) where the ADPCM card is located
port Port number, range or all.
