Axxius 800 - Release 2.2 5-225
CLI Commands
status
status (adpcm)
Use the status (adpcm) command to display the status information for the ADPCM card.
Syntax: status {adpcm-addr}
Example: status 6:1
> status 6:1
SLOT 6:
Status for DS1 1:
Receive: Loss of Signal
Transmit: RAI/Yellow Alarm
Loopback: OFF
{adpcm-addr}
The ADPCM address is in the form {slot|slot:port}. Where {slot} displays information for
all ports on the card, {slot:port} for only the defined port.
slot Slot number (1-8) where the ADPCM card is located
port Port number. range 1-4. If no port is entered all ports will be displayed.
