5-224 Axxius 800 - Release 2.2
CLI Commands
status
status
Use the status command to see the status of the system clocks, DS0s, DS1s, equipment, and the
DS0 Management Channel.
status (adpcm) status equipment
status (adpcm) performance status (fxo)
status (adpcm) performance history status (fxsPS or fxsPSM)
status (bri) status ipds0
status (bri) performance status lsprotect
status (bri) performance history status (ocudp)
status clock status (ocudp) performance
status (ds0) status (ocudp) performance history
status (ds1) status (router)
status (ds1) performance status (router-lan)
status (ds3) performance history status (router-trunk)
status (ds3) status sessions
status (ds3) performance status (v54)
status (ds3) performance history
