Axxius 800 User Manual

5-208 Axxius 800 - Release 2.2
CLI Commands
show
show (router-lan) static
The show (router-lan) static commands to display the current list of static entries for the LAN
on the specified Router card.
show (router-lan) static ip address
The show (router-lan) static ip address command displays the current list of static IP
address entries for the LAN on the specified TSR card.
Syntax: show {rtr_lan-addr} static ip address
Example: show 5:1 static ip address
> show 5:1 static ip address
SLOT 5:
Static IP Address Settings for Axxius50:
Device Name IP Address
----------- ---------------
Axxius122 120.0.0.10
Total: 1
{rtr_lan-addr}
The Router address is in the form {slot:port} or {slot "profile-name"}.
slot The slot number (1-8) that contains the Router card.
port Port number of the Router.
"profile-name" The profile name for the Router interface. Name must be enclosed in
quotes, with a maximum length of 11 characters.
