Axxius 800 - Release 2.2 5-179
CLI Commands
show
show connect
The show connect command displays the static connections for channels and ports.
Syntax: show connect {slot|slot:port|slot:port:channel|
slot:port:channel:sub-channel}
Example: show connect a:1:1-4
From Desc Desc To Comment
A:01:01 DATA DS0
A:01:02 DATA DS0
A:01:03 DATA DS0
A:01:04 DATA DS0
{slot|slot:port|slot:port:channel|slot:port:channel|sub-channel}
slot Slot number A is the Controller card or 1-8 for service cards.
port Port number, range or all.
channel Channel number, range or all.
sub-channel Sub-channel number, range or all.
