CLI Commands
set
set (router-wan) nat enable/disable
Use the set (router-wan) nat command to enable and disable Network Address Translation
(NAT) on a specified WAN interface.
Syntax: set {rtr_card-addr} {"wan-name"} nat {disable|enable}
Example: set 1 "LosAngeles" nat enable
The example will set the WAN interface named "LosAngeles" on the Router
card in slot 1 to enable NAT mapping.
{rtr_card-addr}
The slot number (1-8) that contains the Router card.
{"wan-name"}
The WAN interface to modify. The name must be enclosed in quotes.
{disable|enable}
set (router-wan) nat ports
Use the set (router-wan) nat ports command to configure Network Address Translation
(NAT) to dynamically map ports or preserve them. This field should only be set to
"preserved" if an application that you are using requires a specific port number.
Syntax: set {rtr_card-addr} {"wan-name"} nat ports
{dynamic|preserved}
Example: set 1 "LosAngeles" nat ports dynamic
The example will set the WAN interface named "LosAngeles" on the Router
card in slot 1 to enable dynamic NAT port mapping.
{rtr_card-addr}
The slot number (1-8) that contains the Router card.
{"wan-name"}
The WAN interface to modify. The name must be enclosed in quotes.
{dynamic|preserved}
disable Disable NAT mapping.
enable Enable NAT mapping.
dynamic Set NAT port mapping to be dynamic.
preserved Preserve original port.
