Axxius 800 User Manual

Axxius 800 - Release 2.2 5-151
CLI Commands
set
set (router-trunk) speed
Use the set (router-trunk) speed command to specify the data speed for each DS0 in the
given trunk. This command takes effect upon transition of the trunk to active. This
command applies to the TSR card only.
Syntax: set {tsr-trunk-addr} speed {56|64}
Example: set 3:1:23 speed 56
The example will set the data speed of trunk 23 in the TSR in slot 3 to 56 Kbps.
{tsr-trunk-addr}
{56|64}
set (router-trunk) up/down
Use the set (router-trunk) up/down command to set the WAN trunk up or down. When the
Router trunk is set down a link failure will not cause an alarm. This can be used to eliminate
alarms from Router trunks that are not in-use. When the Router trunk is set up, a link failure on
the WAN trunk will cause an alarm to be reported to the Axxius.
Syntax: set {rtr_trunk-addr} {down|up}
Example: set 2:1:1 down
The example will set the first Router trunk interface on slot 2 down.
{rtr-trunk-addr}
{up|down}
slot Slot number (1-8) that contains the TSR card
port Port number of the Router
trunk Trunk number for this port, 1-24
56 56 Kbps data speed
64 64 Kbps data speed. 64 is the default.
slot Slot number (1-8) that contains the Router card
port Port number of the Router
trunk Trunk number for this port, 1-24
down Set the WAN down.
up Set the WAN up.
