CLI Commands
set
set (router-trunk) encapsulation
Use the set (router-trunk) encapsulation command to specify the encapsulation to use on the
TSR interface.
Syntax: set {rtr_trunk-addr} encapsulation {setting}
Example: set 2:1:5 encapsulation pppofr
The example will configure encapsulation on the Router card in slot 2, port 1,
trunk 5 to PPP over.
{rtr-trunk-addr}
{setting}
set (router-trunk) multilink group
Use the set (router-trunk) multilink group command to specify a Router trunk to be part of a
multilink PPP group. Note: It is recommended, for performance, that all of the individual links
in the multilink group have approximately the same bandwidth.
Syntax: set {rtr-trunk-addr} multilink group {number}
Example: set 3:1:1-2 multilink group 1
The example will form a multilink PPP group that combines trunk 1 and 2.
set 3:1:3 multilink group
The example will add a third trunk to the multilink PPP group from above.
{rtr-trunk-addr}
{number}
The multilink group number.
Range is 1-24.
slot Slot number (1-8) that contains the Router card
port Port number of the Router
trunk Trunk number for this port, 1-24
fr Frame Relay as per RFC 2427
ppp Point-to-Point Protocol (PPP) as per RFC 1661 and 1662
pppofr PPP over Frame Relay as per RFC 1973
slot Slot number (1-8) that contains the Router card
port Port number of the Router
trunk Trunk number for this port, 1-24
