5-98 Axxius 800 - Release 2.2
CLI Commands
set
set (ocudp) loopback
Use the set (ocudp) loopback command to manually set OCU/CSU loopback tests.
Syntax: set {ocudp-addr} loopback {csu|ocu} {loopdown|loopup}
Example: set 3:2 loopback csu loopdown
{ocudp-addr}
The {slot:port} address of the OCU-DP card you want to apply the changes to.
{csu|ocu}
{loopdown|loopup}
slot Slot number (1-8) where the OCU-DP is located
port Port number or range.
csu Set CSU manual loopback tests
ocu Set OCU manual loopback tests
loopdown* Stop CSU/OCU manual loopback test. Loopdown is default.
loopup Start CSU/OCU manual loopback test
