Axxius 800 User Manual

5-96 Axxius 800 - Release 2.2
CLI Commands
set
set lsprotect revertive
Use the set lsprotect revertive command to set low speed protected port(s) to revertive mode.
When a port is set to revertive mode and a failure occurs the port is switched to the protection
port. After 5 minutes, with no failures, the port reverts back. If there are 3 reverts in a 24 hour
period the port is locked out and will remain with the protection port for 24 hours of no failures,
or is manually reset. With 24 hours of no failures one of the 3 reverts is removed from the
counter, and if another failure occurs the counter goes back up to 3 and will go into lockout
mode again.
Syntax: set lsprotect {slot:port} revertive [priority|reset]
[1-7]
Example: set lsprotect 5:2 revertive priority 2
Example: set lsprotect 6:1 revertive reset
Slot 6 Port 1 is currently in protective backup.
Resetting the automatic Lockout will cause service interruption
for port(s) currently being backed up. Traffic will be forced
back to the home port(s)
{slot:port}
The {slot:port} address of the protected port to be configured.
[priority|reset]
[1|2|3|4|5|6|7]
A parameter set with low speed priority, which sets the value of the port priority. Range is
1-7, default is 7. Priority 1 is the highest priority, 7 is the lowest priority.
slot Slot number (1-8) where a Quad T1 card is located
port Port number or range (1-4)
priority An optional parameter, which defines the port priority in the event that
multiple protection requests are received for the same port number on
different cards
reset If the port is already in a protective mode "reset can be selected. The
following message will appear.
