CLI Commands
set
set (fxo)
Use the set (fxo) command to setup one or all of the voice channels of an FXO card. The
command specifies the list of voice channels within that card, and the setting to apply.
Syntax: set {fxo-addr} {setting}
Example: set 2:1 signal ls
Set the FXO on slot 2, port 1 to signaling type loop start.
{fxo-addr}
List of voice channels to apply setting to, in the form {slot:port}.
{setting}
slot Slot number 1-8, location of the FXO card
port Port number or range
rxgain The receive level range is -9 to +7 (db). Available values are -9, -7, -6, -5,
-4, -3, -2, 0, 2, 3, 4, 5, 6, and 7
signal Set the DS0 signaling type
dpt Set the DS0 to Dial Pulse Terminate
gs Set the DS0 to Ground Start signaling
ls Set the DS0 to Loop Start signaling
lscpd Set the DS0 to Loop Start Calling Party Disconnect
txgain The transmit level range is -9 to +7 (db). Available values are -9, -7, -6,
-5, -4, -3, -2, 0, 2, 3, 4, 5, 6, and 7
